Features of Coalbed Gas Generator Sets:
Adapted to a wider range of methane concentrations of Coal Gas
AMICO Coal Gas Generator Sets can be adapted to the concentraction of Coal Gas as low as 8%. The electronic control system can be automatically adjusted when the concentrations are changing in a range; It makes the generator sets are always working in the best condition.
Adcantage of the Gas Engine Technologies
Gas Engine adopts the Lean Burn Combustion Technology, the fuel cost is cheaper. Generating efficiency is higher 15% than other common units, engine exhaust temperature is lower and high reliability.
Generator sets safe and reliable
Amico Coal Gas Generator Sets can operate singly, in parallel or combine with main network. The more, it can achieve the automatic control according to the requirements from customers.
More Comprehensive Protection For the Units
The excellent generator control system with voltage, over current, reverse power protection. As well, it could monitor the engine speed, water and oil temperatures, oil pressure, exhaust temperature and more operating parameters by Remote Control. The units have the failure alarm, limit the power and shutdown protection for the main parameters.
|
Genset |
Fuel |
Coalbed gas |
Coalbed gas |
Coalbed gas |
|
Genset Model |
200GF-WS-AMD |
500GF-WS-AMD |
800GF-WS-AMD |
|
Prime Power |
KW |
200 |
500 |
800 |
|
KVA |
250 |
625 |
1000 |
|
Standby Power |
KW |
220 |
550 |
880 |
|
KVA |
275 |
687.5 |
1100 |
|
Gas consumption |
0.29Nm 3 /kw. h |
0.28Nm 3 /kw. h |
0.26Nm 3 /kw. h |
|
Engine |
Engine Model |
STEYR T12 |
WDT287 |
TBG620V12 |
|
BorexStroke(mm) |
6-155× 126 |
12-138× 160 |
12-170× 195 |
|
Total displacement(L) |
11.592 |
28.7 |
53.11 |
|
Starting Method |
24VDC Electric Start |
|
Intake Method |
Turbocharged& intercooled |
|
Fuel Gontrol |
Oxygen sensor closed loop control |
|
Ignition Control |
Electronically controlled independent cylinder high-energy ignition |
|
Speed Control |
Electronic Speed governing |
|
Rated Speed rpm |
1500 or 1800 |
|
Cooling Method |
Closed-Loop water cooling |
|
Alternater |
Rated Voltage(V) |
230/400 |
230/400 |
230/400 |
|
Rated Current(A) |
360.8 |
902.1 |
1443.2 |
|
Rated Frequency (HZ) |
50 or 60 |
50 or 60 |
50 or 60 |
|
Supply Connection |
3 Phase 4 Lines |
|
Power Factor |
0.8(Delay) |
|
Spec |
Net weight(KG) |
2050 |
4500 |
8800 |
|
Size(L× W× H)mm |
3250× 1150× 1720 |
3700× 1700× 2100 |
5560× 1880× 2350 |
Chengdu Amico Technologies Co., Ltd. is a Gas Power Control Professor with Gas Engine R&D, Control system support, technology training and Selection Services. As well, AMICO is a Professional Manufactory of Gas Engine Power Units and Gas Generator Sets.
Gas Engine Units are independently developed products of AMICO. We use Lean Burn Combustion technology with famous brand gas engines and alternators and gas engine units to achieve the overall electronic control. The applications of Gas Engine Units are wide. The Units can use Natural Gas (Including CNG and LNG), Liquefied Petroleum Gas (LPG), Associated Gas of Oilfield, Coal Bed Gas and Biogas. Our products are widely used in oil and gas fields, coal mines, refusing landfills and other civilian areas.
AMICO is located in Chengdu Modern Industrial Zone with 20000 square meters of R&D and production base. 80% of Employees have received High Education. We have about 30 Senior Engineers, Doctors and Masters. The main engineers of our R&D team have participated in the drafting of Part of the Standards for the Gas Automobiles. We are committed to the 863 Project-Natural Gas Engine Development. AMICO has the Top Automatic Text System and equipment for the Gas Engine Units and Gas Generator Sets. Our company has attained ISO9001: 2000 Quality System Certification and is the "Sichuan High-Tech Enterprise".
AMICO adheres to the motto of "customers first" and has built a sales and service system throughout China, Southeast Asia and other countries and regions. We hope to provide new and old customers with excellent products and perfect service.
