Home Generator Products 200kVA Cummins Engine Power Diesel Engine Generator Set (GF2-200kVA)

200kVA Cummins Engine Power Diesel Engine Generator Set (GF2-200kVA)

200kVA Cummins Engine Power Diesel Engine Generator Set (GF2-200kVA)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P

Our Advantages:

1. Reliable Performance:

Reliable Performance is the major advantage of Hi-earns products, and this reliability is based on the

Outstanding design in every aspect and strict Q. C. System.

2. Customer First:

We devote ourselves to develop products to meet customers' requirements. Our engineer develop and

Design new products for customers.

3. Technical Support and Service: Our engineer team will solve your technical problems within 48 hours.

4. Strict test process before ex-factory:

Every product will be tested twice before ex-factory, and our products are 100% ex factory pass rate.

5. Certification: CE, ISO, , TUV, GS, SONCAP etc.

Warranty policy:

Guarantee for one year or 1000 hours whichever reach first from ex-factory date.

During the guarantee period, Hi-earns Power will provide the free easy-damageable spare parts of diesel

Engine caused by our quality of production or raw material. After expiration, Hiearns Power provides cost

Spare parts maintenance of gensets.

Our service:

1. Our quality department will provide the best solution that make you satisfied efficiently and accurately.

2. If the broken spare parts are in the period under warranty, we will offer this spare parts for free uncder

The condition of this spare parts are not intentionally damaged.
ENGINE DATA
Manufacturer/Model: DCEC Cummins 6CTA8.3-G2,4-cycle
Air Intake System: Turbo,Water/Air Cooling
Fuel System: PB/W type fuel pump
Cylinder Arrangement: 6 in line
Displacement: 8.3L
Bore and Stroke:  114×135(mm)
Compression Ratio: 17.0:1
Rated RPM: 1500rpm
Max.Standby Power at Rated RPM: 180KW /241HP
Governor Type:  Electronic
Exhaust System
Exhaust Gas Flow: 34.7m3/min
Exhaust Temperature: 570 degree
Max Back Pressure: 10kPa
Air Intake System
Max Intake Restriction:  6kPa
Buring Capacity: 12.4m3/min
Intake Flow: 238m3/min
Fuel System
100%(Prime Power) Load: 215 g/Kw.h
75%(Prime Power) Load: 211 g/Kw.h
75%(Prime Power) Load: 216 g/Kw.h
Oil System
Total Oil Capacity: 23.8L
Oil Consumption: ≤ 4g/kwh
Engine Oil Tank Capacity: 18.9L
Oil Pressure at Rated RPM: 276-414kPa
Cooling System
Total Coolant Capacity: 34L
Thermostat: 82-95 degree
Max Water Temperature: 104  degree

ALTERNATOR SPECIFICATION
GENERAL DATA
Compliance with GB755,BS5000,VDE0530,NEMAMG1-22,IED34-1,CSA22.2 and AS 1359 standards.
Alternator Data
Manufacturer: Stamford / Leroy somer / Engga / Marathon / Kaijieli / Dingol
Number of Phase: 3
Connecting Type: 3 Phase and 4 Wires,"Y" type connecting
Number of Bearing: 1
Power Factor: 0.8
Protection Grade: IP23
Altitude: ≤ 1000m
Exciter Type: Brushless,self-exciting
Insulation Class,Temperature Rise: H/H
Telephone Influence Factor(TIF): < 50
THF: < 2%
Voltage Regulation,Steady State: ≤ ±1%
Alternator Capacity: 182KVA
Alternator Efficiencies: 92.40%
Air Cooling Flow: 0.514m3/s

GENERATING SET DATA
Voltage Regulation: ≥ ± 5%
Voltage Regulation,stead state: ≤ ± 1%
Sudden Voltage Warp(100% Sudden Reduce): ≤ +25%
Sudden Voltage Warp( Sudden Increase): ≤ -20%
Voltage Stable Time(100% Sudden Reduce): ≤ 6S
Voltage Stable Time(Sudden Increase): ≤ 6S
Frequency Regulation,Stead State: ≤5 %
Frequency Waving: ≤1.5 %
Sudden Frequency Warp(100% Sudden Reduce): ≤ +12%
Sudden Frequency Warp(Sudden Increase): ≤ -10%
Frequency Recovery Time(100% Sudden Reduce): ≤ 5S
Frequency Recovery Time(Sudden Increase): ≤ 5S
Prod Model: GF2-200KVA
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engine: Cummins Engine
Alternator: Stanford Alternator
Panel: ATS +Digital Panel
Cooling Method: Water Cooling
Stroke: Four Stroke
Installation Method: Fixed
Type: Self-Starting Diesel Generator
Output Type: AC Three Phase
Changzhou Hi-earns Mechanical & Electrical Co., Ltd is established in 2005, which is a high-tech(mechanical&electrical) enterprise, gather "development, production, sales and systematic after-sales services" in one. Our company is certified by ISO9001-2008 QMS, get the EPA approval from U. S. A, CE approval from the European Union, GS approval from Germany and RoHS approval. Our company is one of the most influential enterprise in Eastern China, which is in the field of internal combustion engine.

Our company actively introduce advanced foreign technology and scientific management experience. The company have more than 300 staff, 50 of whom are junior and senior technicists, have 6 advanced automatic production lines. In addition, our company adhere to the brand strategy and international strategy, this greatly improved core competitiveness of us. Our main business includes: Water-cooled diesel generator set, air-cooled diesel engine and generator set, gasoline engine and generator set, water pump, minor agriculture machinery and road machinery equipment. Our company have developed out HR170FB which is turbine type air-cooled diesel engine with the own property right. What's more, this product have gained many certification of practical new-type patent. Our newly developed super silent generator set have got certification of invention patent, and we are the only factory which could produce it. Our company have strong technical force, and perfect after-sales service system. Our products have been sold to many main cities in China, and all over the world including North America, European, South America, Southeast Asia, Middle East, Africa, etc.

"Widely making friends with universal heart, positively returning society with responsible mind", this is the aim of Changzhou Hi-earns Mechanical & Electrical Co., Ltd. In the fierce competition environment, we all Hi-earns staff shoulder to shoulder, insist the faith of "surpassing ourself continuously, developing innovation constantly", and continuously strive for being the first brand of domestic and overseas in mechanical & electrical field, this shows Hi-earns unique enterprise charm and grace, which means "sincerity, diligence, cooperation, devotion". We will continue to build enterprise brand sincerely, gain customers' trust with quality, stand on domestic and overseas market with good price, open the future of Hi-earns with strong ability.
