It is adopt independent tower, without standing cable that is safer and can be use longer.
Our wind power generating set utillize a new aerofoil vertical axis wind wheel and magnetic suspention structure, the high wind engery coeffient, very low start up speed, the high anti-wind capability, high stability, good apreaence. No noise and long service life.
The biades have adopted glass reinforced plastic material and process in injection molding, accompanied with the optimized air operated shape design, the usage factor of wind power is much higher under the same totor swept area and the wastaga of the material is much lower than before.
|
Mode |
1000W |
|
Output voltage(V |
220 |
|
Color |
white |
|
Tyre |
vertical |
|
Noise |
very low |
|
Materia |
fiberglass |
|
Protection grade |
IP54 |
|
the diameter of the lable |
1.8 |
|
rated rotate speed |
60r/min |
|
rate wind speed |
10m/s |
|
start up wind speed |
2m/s |
|
security wing speed |
50m/s |
|
working wind speed |
3-25 |
|
rated voltage |
24v |
|
the height of the tower |
8m |
|
rated power |
1000W |
|
guidable tow tyre |
114*6 |
|
the max power |
1500W |
|
output control |
charger control. interver |
|
battery reference |
12v 100ah, 4pcs |
|
Packing |
polywood packing
|
Windpower Engery Co. Limited, located in Shenzhen, one of China's coastal cities, take advantage of the natural resources, we export wind power system to world wide.
We have years experience in exporting. We have gained prestige from our customers.
