We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), please contact us for more detail informations.
Features of permanent magnet generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Model | Rated power ( W ) | Rated voltage ( V ) | Rated rotated speed ( rpm ) | Startup torque ( N*M ) | Efficiency |
| LSL-50W | 50 | DC14 | 200 | 0.25 | 70% |
| LSL-100W | 100 | DC14 | 200 | 0.35 | 75% |
| LSL-200W | 200 | DC28 | 200 | 0.65 | 78% |
| LSL-300W | 300 | DC28 | 200 | 0.7 | 78% |
| LSL-500W | 500 | DC28 | 200 | 1.2 | 78% |
| LSL-1000W | 1K | DC56 | 200 | 2 | 88% |
| LSL-2000W | 2K | DC115 | 200 | 2.5 | 85% |
| LSL-3000W | 3K | DC115 | 300 | 2.5 | 85% |
| LSL-5000W | 5K | AC230 | 200 | 4 | 88% |
| LSL-10KW | 10K | AC230 | 200 | 6.5 | 90% |
| LSL-20KW | 20K | AC400 | 150 | 15 | 90% |
| LSL-50KW | 50K | AC690 | 150 | 40 | 90% |
| LSL-100KW | 100K | AC690 | 140 | 85 | 90% |
| LSL-300KW | 300K | AC690 | 350 | 185 | 90% |
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
