Established in 1994, HuaTai Power Company is a leading manufacture of Diesel Generator manufacturer.
Specifications configuration
1. Rating Voltage: 400v/230v
2. Frequency: 50/60Hz
3. Rated power range: 5-27KW, 7-33KVA
4. Model of connection: 3 phase 4 line
5. Power factor: 0.8(lagging)
6. Protection standard: H
7. Insulation grade: H
8. Cooling method: Water cooked
9. Cylinder numbers: 3/4
10. Engine Model: YSAD380G, Y385G, YD480G, YND485G, YSD490G, Y4100G, Y4102G
11. Alternator: Stamford, Marathon, Copy Stamford, Leroy Somer, etc.
12. Control system: Intelligent controlling system, all English display, friendly operation interface.
13. Type:
Opten type
Sound-proof canopy
Canopy with wheels.
Container type canopy
14. The panel is including: A)Standard engine instrumentation b)Voltmeter with selector switch c)Ammeter with selector switch d)Frequency meter e)Current transformers f)Instrument fuses duly wired and ferruled g)MCB of suitable rating with overload and short circuit protection h)With AMF control panet or with ATS(automatic transfer system)
Lead time: 25 days for open type and 30days for silent type.
Genset Model | | Enigne Model | GOVERNOR | CYLINDERS | ASPIRATION | BORE | STROKE | Cooling Water Capacity | Lub oil Capacitor | Engine Maximum Power |
RATED POWER(KVA) | RATED POWER(KW) | 1500RPM |
H-Y8 | 7 | 5 | YSAD380G | M | 3 | N | 80 | 90 | 15 | 1.357 | 10.3 |
H-Y9 | 8 | 6 | Y385G | M | 3 | N | 85 | 90 | 15 | 1.532 | 11.2 |
H-Y13 | 11 | 9 | YD480G | M | 4 | N | 80 | 90 | 23 | 1.809 | 15.8 |
H-Y15 | 14 | 11 | YND485G | M | 4 | N | 85 | 95 | 23 | 2.156 | 18 |
H-Y20 | 18 | 15 | YSD490G | M | 4 | N | 90 | 100 | 23 | 2.54 | 23.6 |
H-Y31 | 28 | 23 | Y4100G | M | 4 | N | 100 | 105 | 23 | 3.298 | 28 |
H-Y32 | 30 | 24 | Y4102G | M | 4 | N | 102 | 118 | 23 | 3.857 | 31 |
Invested by international and domestic financial groups, Fujian HuaTai Power Supply Co., Ltd. specializes in assembling, vending and maintaining imported diesel generator sets. With professional experience of designing, configuring and maintaining power generator sets, our products have successfully maintained domestic market of all industries, and we have gained OEM permission for brands of Deutz, John Deere, Daewoo diesel generators and etc.
