Technical Data of Wind Turbine 1000W
Rated Power(W) 1000
Rated Voltage(DVC) 48
Rated Currency(DCA) 21
Output Voltage of Inverter Single phase 110V-120V/2220-240Vac/50Hz or 60 Hz
Rotor Diameter(M) 3.0
Start-up Wind Speed(m/s) 2
Rated Wind Speed(m/s) 9
Security Wind Speed 35
Direction(Looking down wind) Counterclockwise
Location relative to tower Upwind
Over Speed Protection Auto Furl
Temperature Range -40 to+60Deg. C (-40 to +140Deg. F)
Rated Rotating Rate(r/m) 400
Shell Material Aluminum Alloy
Blade Material Glass Fiber
Blade Quantity 3
Height of Guy-Cable Tower(m) 6
Generator Three phase permanent magnet synchronous generator
Output Form 48VDC Nominal
Power Yield per Year (KWH) 12019
Efficiency 85%
Suggested Battery Capacity Lead Acid or Colloid 12V200Ah 4PCS
Control System Controller and Sine Wave Inverter
Standard Supply Scope Wind turbine generator system including turbine, hub, controller, off grid inverter, blades, tower and other accessories.
Turbine Life Span Around 20 years under normal wind conditions.
HULK ENERGY has for over 10 years been specializing designing and distributing wind and solar power products. We service everything we sell. We have seen scores of companies come and go, but we have consistently been here to take care of our customers. We supply good quality, low-priced renewable energy systems - proving that renewable power need not cost the earth. We've provided you very comprehensive alternative energy products, including complete systems, solar panels, wind power generators, solar light system, solar mounting systems, electric, inverters, controllers and batteries. Our mission is to demonstrate that green energy is genuinely viable, whether you are living on or off grid - and that renewable energy can be a sound financial investment, as well as a sound investment in our future.
We believe that Alternative Energy products should not only be utilitarian, but also be aesthetically pleasing to look at. Our experience means that we will execute our services as efficiently as humanly possible. And lastly, we believe in innovation and creativity, finding new ways to serve our customers better.
