Nantong Fengyuan Wind Turbine Manufacturing Co., Ltd is a high-tech enterprise specialized in producing small and medium-sized wind generators as well as the products supported, including the whole process of product researching, manufacturing and sales.
The company mainly produces small wind turbines, including 300W, 400w\500w\1kw\2kw\3kw\5kw\10kw and 20kw. In addition, city solar-wind complementary lamp systems are also provided with the supporting services.
Product components such as blade, generator, controller and towers are all self-designed through comparing tests, the performance is better than the average. Welcome you, the guests, to compare and select.
The products are awarded with CE certificates, to be sold in domestic markets and exported to more than 40 countries such as the UK, France, USA, Canada, New Zealand, Australia, Argentina, India, etc.
Technical Data |
Model | FD-300 | FD-400 | FD-500 | FD-1000 | FD-2000 | FD-3000 | FD-5000 | FD-10000 |
Rated Power(W) | 300 | 400 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 |
rated voltage(V) | AC24 | AC24 | AC24 | AC48 | AC96 | AC240 | AC240 | AC240 |
blade diameter(m) | 1.5 | 2.1 | 2.8 | 3.2 | 4.2 | 5.5 | 6.2 | 7.5 |
start up wind speed(m/s) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 |
Rated Wind Speed(m/s) | 400 | 600 | 320 | 280 | 280 | 220 | 200 | 160 |
survival wind speed(m/s) | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
rated speed(m/s) | 400 | 600 | 320 | 280 | 280 | 220 | 200 | 160 |
yaw method | mechanical yaw | mechanical yaw | mechanical yaw | mechanical yaw | mechanical yaw | automatic control | automatic control | automatic control |
braking mode | centrifugal | centrifugal | rear wings & dynamic braking | rear wings & dynamic braking | rear wings & dynamic braking | dynamic braking | dynamic braking | dynamic braking |
engine shell Material | aluminum alloy | aluminum alloy | aluminum alloy | aluminum alloy | aluminum alloy | steel | steel | steel |
blade material | glass fiber reinforced plastics | aluminum alloy | glass fiber reinforced plastics | glass fiber reinforced plastics | glass fiber reinforced plastics | glass fiber reinforced plastics | glass fiber reinforced plastics | glass fiber reinforced plastics |
main part weight(kg) | 25 | 31 | 28 | 34 | 39 | 280 | 325 | 387 |
guyed tower | Height(m) | 6.00 | 6.00 | 6.00 | 6.00 | 9 | 9 | | |
Diameter(mm) | 76 | 76 | 76 | 89 | 114 | 273 | | |
Weight(kg) | 35 | 35 | 35 | 45 | 90 | 385 | | |
free stand tower | Height(m) | 8 | 8 | 8 | 9 | 9 | 12 | 12 | 15 |
Diameter(mm) | 4.5 | 4.5 | 4.5 | 5.5 | 5.5 | 6 | 6 | 8 |
Weight(kg) | 180 | 180 | 180 | 390 | 390 | 820 | 1090 | 1250 |
Suggested matching battery | two batteries of 12V 100AH | two batteries of 12V 101AH | two batteries of 12V 150AH | four batteries of 12V 150AH | eight batteries of 12V 150AH | 20 batteries of 12V 200AH | 20 batteries of 12V 300AH | 20 batteries of 12V 400AH |
|
inverter | Off-grid/sine wave | Off-grid/sine wave | off-grid/sychronization,sine wave | off-grid/sychronization,sine wave | off-grid/sychronization,sine wave | off-grid/sychronization,sine wave | off-grid/sychronization,sine wave | off-grid/sychronization,sine wave |
load | scenery complementary lamps,small TV,illumination, fan,charge | scenery complementary lamps,small TV,illumination, fan,charge | scenery complementary lamps,small TV,illumination, fan,charge | small refreigerator,small valve TV,illumination, fan,charge | refreigerator,washing machine valve,TV electric cooker,illumination, fan,charge | air conditioner,refreigerator,washing machine valve,TV electric cooker,illumination, fan,charge | air conditioner,refreigerator,washing machine valve,TV electric cooker,illumination, fan,charge | air conditioner,refreigerator,washing machine valve,TV electric cooker,illumination, fan,charge for multiple families |
Nantong fengyuan wind turbine manufacturing Co., Ltd is a high-tech enterprise specialized in producing small and medium-sized wind generators as well as the products supported, including the whole process of product researching, manufacturing and sales.
The company emphasizes on scientific researching and developing, possessing a batch of talents on aerodynamic analysis, mechanical and electric motor design and manufacturing. Based on the basic theory, each model has been through scientific analysis, including the aerodynamic calculation, intensity researching, efficiency study, electromagnetic calculation, vibration and matching analysis. Each generator is tested with reports according to the detailed design and plan for the performance of each process. He company mainly produces small wind turbines, including 300w, 400w\500w\1kw\2kw\3kw\5kw\10kw and 20kw. In addition, city solar-wind complementary lamp systems are also provided with the supporting services. Based on ISO9001 management system, the company possessed advanced production and detection facilities under high technology with strict management processes. All products are tested rigorously to achieve relevant national standards. Product components such as blade, generator, controller and towers are all self-designed through comparing tests, the performance is better than the average. Welcome you, the guests, to compare and select. The products are awarded with CE certificates, to be sold in domestic markets and exported to more than 40 countries such as the UK, France, USA, Canada, New Zealand, Australia, Argentina, India, etc. The company has a real wind turbine platform for customer visiting. Welcome you to visit and consult.
