Rated power(W) 5000
Rated voltage(DCV) 240
Rated current(DCA) 21
Rotor diameter(m) 6.4
Blade material GFRP
Rotation direction Clockwise
Start-up wind speed(m/s) 2.5
Rated wind speed(m/s) 10
Cut-out wind speed(m/s) 16
Survival wind speed(m/s) 45
Net weight(T) 1.0
Wind turbine type Upwind
Rated Rotating speed(RPM) 200
Blades No. 3
Hydraulic tower height(m) 12
Yaw mechanism Hydraulic
Annual yield(kwh) 24000
Yaw mode Auto/manual
Cable length (m) 20
Efficiency 0.6
Wind turbine tilt-angle 6°
Protection mode -Yaw
-Hydraulic brake
-Dump loader
Hangzhou Grand New Energy Co., Ltd. was founded in 2003, which located in Hangzhou city, Zhejiang province. We are dedicated to the manufacturing and promotion of renewable energy product. We believe that Renewable energy will lead to Sustainable Development.
Our core product includes Wind Turbine(wind generator) and LED Street Light. Our products have got CE certification and has been well recognized in the market.
We have the most advanced production line in China with many years' experience in exporting. 80% of our products are exported to overseas market.
With the strict quality control and continuous product innovations, we has got great achievement from the increasing competitions. We have first-class testing systems to ensure our products with high quality. On the other hand, we have a professional and technical laboratory, which has a wide cooperation with other companies and research institutes, and it offers great support to our production by providing innovative technologies.
Hangzhou Grand New Energy Co., Ltd insist on the principle of "Quality First, Customer First, Service First", provide costumers with the most reasonable price and good quality.
