Rrare earth NdFeB 42HS permanent magnet generator
Rated rotate speed: 300rpm
Output voltage: DC115V13.0AH
Starting torque<1.75
Efficiency >85%
Rotor Blade
Material: FRP Carbon Fiber
With epoxy resin covering, keep the blade clean
Rotor diameter: 3.5m
Speed regular method: Yawing + electromagnetic brake
Wind-speed
Cut-in windspeed: 3m/s
Rated windspeed: 8m/s
Work windspeed: 3m-25m/s
Survival windspeed: 50m/s
Rated output power: 1.5KW
Max output power: 2.5KW
Output voltage: AC 220V
Battery bank
Free maintenance lead-acid battery
Specification: 12V 150AH
Recombination efficiency >99.6%
Work temperature: -20 to +50° C
Controller system
Controller & wine wave inverter
1.5KW
Wind turbine head: 115kgs
Tower type: Steel pipe with guy rope
Steel pipe diameter(outer): 139x7mm
Tow pipe height: 6-8m
Packing details: Fumigation-free wooden box and soft package
Established in 1997's, Guangzhou Richsum Electronics Ltd. is dedicated to solar and wind power industry.
We are engaged in the deepest level exploitation on silicone material, solar cell and generator unit, design and produce solar panel, solar power system, wind turnbine generator, solar road light projects, we provide our clients with optimized, high efficiency, reliable complete solutions, and undertake construction project or provide with technical supports.
We originate from layouts and manufactures of radios, RFID, chargers and LED products at the beginning of establishment.
As an excellent enterprise with more than 10 years' experiences and more than 600 skilled employees, our company owns complete design and manufacturing equipments and a whole set of quality guarantee system, depending on our owned advantage, our target is to create the more economic and social benefits for our customers.
In order to support our customers, we have our own professional printing workshops and metal factory.
Our main markets are America, Europe, South Africa and Australia. Please feel free to contact us for further information.
