Specification
(1). Rated power----- 600W
(2). OUTPUT voltage----- 24V
(3). Rotor diameter----- 2.8m
(4). Start-up wind speed ----- 3m/s
(5). Rated wind speed------ 8m/s
(6). Security wind speed ----- 3-25m/s
(7). Rated rotating rate----- 400r/m
(8). Generator work way----- Permanent magnetism three phase alternating current
(9). Speed-limitation mechanism----- Yaw & electromagnetic brake
(10). Blade material----- glass fibre reinforced
(11). Blade quantity----- 3
(12). Packing----- Plywood Box
(13). Tower hight----- 6m
(14). Tower thickness----- 4mm
(15). Tower diameter----- 76mm
(16). Tower height ----- 6m
(17). Suggested battery capacity----- 12V150AH*2PCS
(18). Matched inverter type------ pure sinewave
(19). Can supply power for ------- Lighting, Electric Fan, Charge
1. Provide OEM
2. Home use
3. Factory
4. Low start-up wind speed
5. Permanent magnetic
6.40% more electricity generated
7. Easy to intall
8. Good quality, High performance
9. Long lifespan 25years, Cost-effective
Power |
600W |
Blade Diameter |
2.8m |
Rated Rotor Speed |
400r/min |
R ated Speed |
8m /s |
Rated Power |
600W |
M ax Power |
1000w |
O utput Voltage |
24V |
S tart up Wind Speed |
3m /s |
W ork Speed |
3-25m/s |
Security Wind Speed |
40m /s |
H eight of Tower |
6m |
Top Weight Except Tower |
85kg |
T ower Type |
ø 76mm steel tube |
O utput Controller System |
Controller, Inverter |
Suggested Batteries and It’ s Capacity |
2 PCS 12V100AH |
Can Supply Power For |
SMALL REFRIGERATOR, WASHING MACHINE, WATERPUMP (375), TV, LIGHTING, ELECTRIC FAN AND CHARGING |
