1, high generating efficiency
2, light weight, low starting torque
3, appealing appearance
4, easy installation
5. FRP(Fiber glass reinforced*3) blades.
6. Permanent-magnet-phase/3phases A. C
7. House/small village used.
8, range from 500W to 100kw.
Power (w) |
600w |
2000w |
10000W |
Type of generator |
permanent-magnet-phase
A. C |
permanent-magnet-3phase
A. C |
permanent-magnet-3phase
A. C |
Blade diameter (m) |
2.8 |
4 |
8 |
Blade material |
FRP
(Fiber glass reinforced*3) |
FRP
(Fiber glass reinforced*3) |
FRP
(Fiber glass reinforced*3) |
rated rotor speed(r/min) |
400 |
400 |
200 |
Rated speed(m/s) |
8 |
8 |
10 |
Rated power (w) |
600 |
2000 |
10, 000 |
Max power(w) |
750 |
3000 |
15, 000 |
Output voltage(v) |
DC24/AC220/50HZ |
DC96V/AV220/50HZ |
DC380/AC220/50HZ |
Start up wind speed(m/s) |
3 |
3 |
3 |
Operating wind speed(m/s) |
3-25 |
3-25 |
3-25 |
Secunity wind speed(m/s) |
40 |
40 |
40 |
Rate-limiting mode |
Rotating empennage
+reluctance |
Rotating empennage
+reluctance |
Hydraulic brakes,
PLC control |
height of guy cable tower |
6m(75*4)
Galvanized seamless
steel pipe surfuace,
then spray antiseptic
white pain |
8m(133*5) |
12m(159*5)
Galvanized seamless
steel pipe surfuace,
then spray antiseptic
white pain |
Weight of top section(kg) |
45.9 |
83 |
600 |
total weight (kg) |
98.6 |
180 |
1463 |
output controller system |
controller, inverter |
controller, inverter |
controller, inverter |
Capacity and quantity
of battery (reference) |
12V 150AH 2PCS |
12V 100AH 8PCS |
12V 150AH 30PCS |
can supply power for |
washing machine, TV,
lighter, fan, charger |
refrigerator,
washing machine,
water pump,
tv, lighting, eletric fan,
air condition, charger |
refrigerator,
washing machine,
water pump,
tv, lighting, eletric fan,
air condition,
small village |
