Model BMH-1KW Rotor diameter 3.2m
Blades quantity 3 PCS Blades material FRP (composite material)
Rated speed 360r/min Rated output power 1KW
Max output power 1500W Output voltage DC48V/AC220V
Start wind speed 3m/s Rated wind speed 8m/s
Working wind speed 3-25m/s Security wind speed 40m/s
Speed regulation yaw& magnetic resistance Charge control AIC (automatic intelligent control)
Wind turbine type PMG (onconstantmagnets) Working temperature from -40 to +60 C
Annual average energy production 2500kWh Recommended accumulators 12V150AH4PCS( 600Ah )
Accumulators full charge time about 8 hours Tower type pull wire tubular tower or cone tower(optinal)
Tower height 6m (optional) Weight 45kgs (without tower)
CAN SUPPLY POWER FOR water pump. TV. Washer. Illumine. Fanner. Charge
Guangzhou Bilon Energy Sources Technology Co., Ltd is full of spirits and passions'company, which mainly run all kinds of renewable power and generator sets etc machines of power driving, have accumulated the abundant experiences and relationships, become ourselves systemic supplying channels and have a perfect start on developing the world market. Bilon believes, in the intending time, we will continue to insist in a principle-serve sincerely, rapid response, walk firmly on the present road.
