We are professional produce wind turbine factory. We have a professional researching team. Our pruducts mainly is 300W-30KW wind turbines. Our all products are mature products. They can work in very poor environent. Life is 15-20 years.
Item
Price(RMB) ()note( Technical Parameter)
300W
300w Head assembly 1992: \\\\\\.
It contains a PMG, three blades, a blade flange, a rectifier hat. A slip ring, a tail wing and a upper Pedestal.
Wind & Solar complementary Controller and Inverter 650/.
Function: Overcharge protection, under-voltage protection, overload protection, solar panels interface and auto-control (photo-control, time can set )
Battery 2000/ 12V200AH, 300W, 4000
Battery standard is 12V200AH. 300W wind turbine needs 2 batteries. Full price is 4000RMB.
Solar panels 16/ 160W,: 2560
300W wind turbine needs 160W solar panel that is Monocrystalline Silicon. This price contains support. Solar panels full price is 2560RMB
Blade 360: 1.7-2.5m, 2m/s, 7m/s, 26m/s, .
Blades diameter is 1.7m or 2.5m. Cut-in speed is 2m/s. Rated speed is 7m/s. Cut-out speed is 26m/s. Blade price is contained in head assembly.
Tapered tower pole 3700/ 9.135/205 250/450
Tower pole height is 9 m. Its color is white. Top diameter is 135/205mm. Bottom diameter is 250/450mm.
| NanjingTianNeng Wind power generator price list(300W) |
| 300w-3ph. Generator(PMG) | Wind/Solar Hybrid Controller and Inverter | blade | guyed tower | Head assembly |
| Rated voltage | 24-28V | Solar panels | 0V-36V | Materials | High strength GFRP | Materials | Steel pipe | balde | 3 |
| 0W-400W |
| Rated Current | 10.7 A | Accumulator cell | 12V200AH*1 | Diameter | 1.7-2.5m | Diameter | 60mm | bladeflange | 1 |
| 12V-24V | cut-in speed | 2m/s | height | 6m | Rectification hat | 1 |
| Rated speed | 350r/min | Function | Instruction booklet | Rated wind speed | 7m/s | Fitting diameter | 8mm | Slipring | 1 |
| External dimensions(mm) | 160*295 | External dimensions (mm) | 320*240*120 | cut-out speed | 26m/s | lower seat | A set | Tail wing | A set |
| EMBED | A set | Upper pedestal | A set |
| Weight | 12KG | Weight | 3KG | Weight | 5KG | Weight | 35KG | Weight | 24KG |
| Price(usd) | 116 | Price(usd) | 96 | Price(usd) | 53 | Price(usd) | 35 | Price(usd) | 274 |
| complete set | volume(cm) | 200*40*40 | volume(kg) | 105 | full price(usd) | 423 |
| FOB price(usd) | 510 |
| Note | The above price does not contain the battery and the solar panels. If needs accumulator cell whose price is 265USD/piece. If needs the solar panels whose price is 2.4USD/w. Include domestic transport costs and packing costs. |
| This price retains for three months |
| Contact person: Mr. Chen Tel:013002546923 Tel:+86+025-52627271 FAX:+86+025-52814664 |
| Web:www.njtianneng.com E-Mail:[email protected] |
The company is located in Nanjing district, like the paintings of the Yangtze River, and Nanjing Lukou International Airport, located a few kilometers. The company is engaged in the wind energy technology behind and inverter product development, production and sales of high-tech industry, advanced production equipment and professional testing facilities. Sold in Inner Mongolia, Xinjiang, Heilongjiang, Hainan and other provinces across the country. Sold to Myanmar, Chile, Malaysia, Korea, Argentina, and other non-European countries and territories, by the user's welcome. Our company purpose: Research, development and production. Take advantage of the new green energy. Founded the reputation of wind energy products, Nanjing Jiangsu Province, and will continue to research new wind energy products. Contributing to society, for the benefit of mankind. The company is developing and manufacturing wind turbines, wind-power pumping professional private enterprises with a registered capital of 5 million Yuan. Our company has formed a unique concept and business model in wind energy development. Our company of high quality is the only means of survival and development of, sincere service good every customer.
