Wind Generator
Model: PM-10KW
Wind Generator 10KW Wind Turbine Generator
Wind Generator Rotor diameter: 8m
Wind Generator Blades quantity: 3 pcs
Wind Generator Direction: Always downwind
Wind Generator Blades material: Glass fiber reinforced plastic
Wind Generator Rated output: 10000W
Wind Generator Maximum output: 12000W
Wind Generator Initial voltage: 280V
Initial wind speed: 2m/s
Nominal wind speed: 10m/s
Stormstand: Up to 45m/s
Wind protection: AutoFurl
Rotor speed: 160 turns per min
Wind turbine type: PMG (on constant magnets)
Working temperature: From -40 to +60 C
Annual average energy production: 25000kWh
Charge control: AIC (automatic intelligent control)
Recommended accumulators: 12V400AH 20PC
Accumulators full charge time: About 12 hours
Weight: 449kg(without mast)
Pre-Max is a advanced technology company in the industry of wind generator. We specialize in small sized wind generating system, developing solutions for setting up wind power plants. 20 years experience in this industry, starting from making military motor and electrical products. Now the company is focusing wind products, investing in the technology and cooperating with University of Zhejiang keep Pre-Max running the latest technology.
Pre-Max provides various type models of wind generators from 300W to 50KW with the voltage from 12V to 420V. Besides, it also gather the electrical energy transformation and alternating current supply which voltage and hertz is 220V/50HZ, 110V/60HZ, 230V/50HZ.
Also the company offers excellent services with great prices to benefit all overseas clients. Looking forward to cooperating with you.
