The vertical axis wind turbine of 300W-10KW is unlike any other on the market today.
It differs from ordinary wind turbines because its vertical design saves space and can lead to greater over-all efficiency. This turbine is designed for on-the-grid, off-the-grid, public, private, and business use.
|
Model |
300W |
500W |
1KW |
2KW |
3KW |
5KW |
10KW |
|
The Diameter Of Wind Wheel |
2.0m |
2.0m |
2.5m |
2.5m |
3.2m |
3.2m |
4.0m |
|
Blades Number (FRP) |
5 |
7 |
5 |
7 |
7 |
9 |
7 |
|
Blades Length |
1120mm |
1120mm |
1650mm |
1650mm |
1830mm |
1830mm |
3600mm |
|
Rated Rotate Speed |
80(r/min) |
80(r/min) |
55(r/min) |
50(r/min) |
50(r/min) |
50(r/min) |
50(r/min) |
|
Rated Wind Speed |
8 m/s |
8 m/s |
10 m/s |
10 m/s |
11 m/s |
11 m/s |
12m/s |
|
Start Up Wind Speed |
2m/s |
2m/s |
2.5m/s |
2.5m/s |
2.5m/s |
2.5m/s |
3m/s |
|
Working Wind Speed |
3-25(m/s) |
3-25(m/s) |
3-25(m/s) |
3-25(m/s) |
3-30(m/s) |
3-30(m/s) |
4-30(m/s) |
|
Security Wind Speed |
40m/s |
40m/s |
40m/s |
40(m/s) |
40(m/s) |
40(m/s) |
40(m/s) |
|
Rated Power |
300W |
500W |
1KW |
2KW |
3KW |
5KW |
10KW |
|
The Max Power |
350W |
550W |
1.5KW |
2.5KW |
3.5KW |
6KW |
11KW |
|
Rated Voltage |
24V |
24V |
24V/48V |
48V/96V |
220V |
220V |
380V |
|
The Height Of Tower |
6m |
6m |
8m |
8m |
8m |
9m |
12m |
|
Guy Cable Tower Type(Mm) |
89*6 |
96*6 |
114*6 |
114*6 |
203*6 |
203*6 |
245*6 |
|
Output Control System |
charger control, inverter |
charger control, inverter |
charger control, inverter |
charger control, inverter |
charger control, inverter |
charger control, inverter |
charger control, inverter |
|
Battery Reference |
12V100ah, 2pcs |
12V100ah, 2pcs |
12V100ah, 4pcs |
12v150ah 4pcs/12V100ah 8pcs |
12v100ah 18pcs |
12V150ah,18 pcs |
12V200ah,30pcs |
