Yuchai series engine adopt the power type engine researched by German FEV corporate.
The engine use the whole crankshaft, alloy cast iron engine body and cylinder head. With the small volume, light weight and high reliability, the engine can runs more than 10000 hours. Yuchai engine has advantage of fuel-efficient, four-valve technology, better combustion, small exhaust, low fuel consumption and curve flat. The power covers from 20kw to 500kw.
| 50KW DIESEL GENERATOR DETAILS |
| Model | HQ300GF | Start Method | DC 24 |
| Generator Prime Power(KW/KVA) | 300 | Output Current(A) | 540 |
| Standby Power(KW/KVA) | 330 | Voltage(V) | 400/230 |
| Power Factor | 0.8 | Phase | Three phase, Four Wires |
| Frequency(Hz) | 50 | Weight(kg) | 2150 |
| Size(mm) | L | W | G |
| 3200 | 1200 | 1750 |
| Diesel Engine Data |
| Manufacturer | Yuchai | Model | YC6T500L-D20 |
| Rated Speed(Rpm) | 1500 | Diesel Engine Max Power(KW/H) | 330 |
| Cylinder No. | 6 | Arrangement Type | In-line |
| Bore×Stroke(mm) | 129×155 | Displacement(L) | 3.61 |
| Intake Method | Turbocharged | Compression ratio | 17.5:1 |
| Fuel | Diesel Fuel | Full Load Consumption(g/kw.h) | ≤209 |
| Oil Capacity(L) | 14 | Start Method | Electrical |
| Engine Cooled Method | Radiator Max 40ºC,fans are driven by belt with safety guard. |
| Alternator Data |
| Manufacturer | China Stanford | Model | XN300 |
| Rated Power(KW/KVA) | 300/330 | Excitation Type | Brushless |
| Insulation Class | H | Protection Grade | IP22 |
| Unload Voltage Adjustment | ≥±5% | Stable Voltage Adjustment | ±1% |
| Efficiency (%) | 94.8 | Voltage Control Method | AVR |
Guangxi Yuchai Diesel Generator Set Features:
1. Diesel generator adopt the Guangxi original Yuchai engine, as the main power support.
Engine charactors: Injection, Inline.Four stroke,water-cooled
2. Yuchai engine basic its years experience,produce the more strong ,stable and low fuel cost engine.
Widely used as continous work area, continous working time more than 48 hours.
3. Yuchai engine strong power,stable,long working life,low fuel cost, and price economic, price lower than Deutz, Cummins engine etc.Widely used in Factory, Project, Shop,Hospital ,Train,Aireport,station etc areas.
4. Alternator, adopt option brand like China brush alternator, Stamford, Farady, Marathon,Leroy-somer, Lanzhou,etc so famous brands alternators.
5.This series diesel generator is the special type we promotion for abroad market, and make the highly quality level than other configurations.
6.Diesel generator including abersorber system,and protect the generator during its working time.
7.All generator surface after acidification , and suitalbe wet condtion working .
8.Standard control panel design basic the operation,and easy show all meters you care during generator working time.
9.Structure: adopt the high strong steel make the under frame, and easy moved and stable long life.
10.We offer options generators as the below shows:
A.Frequency we offer 50HZ and 60HZ.
B.Voltage: we offer 110/220v, 240v,380v/440v,254v/440 etc,or depend on your request.
C.Phase: we offer three phase or single phase generator
D.Options parts like: Electric speed adjustment, LCD show panel,protection system,Automatic transfer system. Silent canopy, Weatherproof canopy,Fuel tank.
the usage of yuchai diesel generator
Diesel engine: Forged steel crankshaft made in a single piece, and cylinder head made out of high-quality alloy cast iron; imported cylinder block rough cast features with smaller in size, lighter in weight, less vibration, lower noise and higher reliability; and featured with the low fuel consumption; lower emission, strong power, and the overall period is more than 12000 hours. It also get the EU, Russia and other countries certifications. More than 2000 vehicles with the Yuchai series IV6l SERIES IV Emission engines served the 2008 Beijing Olympic Games, Yuchai was the only engine supplier for Beijing Olympic bus service.
FAQ
1. Q:What is your MOQ of this item?
A: Sample order is acceptable.
2. Q: What is the lead time?
A: As usually, 25-35 days after receiving TT deposit or L/C. But we will finish order with shorter time for your urgent need.
3. Q: Where is your loading sea port?
A: Fuzhou, China.
4. Q: Is it all right to make customer's own brand name?
A: We can be your OEM manafacture with your authorization of brand..
5. Q: What is your company available production capactiy?
A: One 40HQ container can be finished per day. The more quantities, the same delivery time.
Payment term:
1, TT(30%advance,the balance is paid before dispatch)
Delivery time:
Within 30days after receiving T/T 30% advance or L/C at sight.
Warranty
(1) Guarantee for one year or 1000hours (according to whichever reaches first) from ex-factory date.
(2) During guarantee period,our company will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material.
Our Service:
Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, JLT-Power will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, JLT-Power provides cost spare parts maintenance of engine & alternator.
Huaquan Power is specialized in producing diesel generator set, diesel generator, generator set, diesel generating set, generating, generating set, generator diesel, power generator, gas generator, nautral gas generator, eletric generator, alternator, diesel engine etc. We have open frame generator, automatic generator, trailer generator, silent/soundproof diesel generator, water pump etc. And the brands include Cummins, Perkins, Deutz, Steyr, Isuzu, Ricardo, Yuchai, as well as famous brands of alternator, such as Stamford, Faraday, Leroy-somer, Qiji. Power ranges from 3kw to 1000kw
Huaquan Power Mchinery Co., Ltd, located in diesel engine manufacturing powerhouse-Weifang, the capital of kites.
Huaquan Power has more than 500 employees worldwide and it has four advanced production lines, sophisticated testing equipment, complete quality management system, and marketing all around the world in the past 10 years, such as Southeast Asia, the Middle East, Africa and other regions.
Huaquan Power ensures that providing the energy saving, environment protection, high quality and reliable diesel engine and generators, to ensure user satisfaction and rest assured! We sincerely look forward to your cooperation!
