Bronco relies on scientific research and marketing guide,fetching in advanced technology, materials and productive techniques, developing new products ceaselessly. And parts of our products have reached the leader level in China.Many of our products have exported to Europe, American, Middle East, East-south in Asia.
|
Engine model |
BN186F/E |
|
Rated output power(kw) |
2 |
|
Max.output power(kw) |
2.2 |
|
Rated frenquency(HZ) |
50 |
|
Rated voltage(v) |
230 |
|
Rated current(A) |
8.7 |
|
Rated rotation speed(RPM) |
3000 |
|
Power factor(cosφ) |
1 |
|
Bore*Stroke(mm) |
86*70 |
|
Compression ratio |
19:1 |
|
Rotation direction |
clockwise |
|
Lubrication sysytem |
pressure splahed |
|
Lube oil type |
SAE-10W30(above DC grade) |
|
Displacement(cc) |
406 |
|
Rated welding voltage(V) |
55-65 |
|
Rated welding direct current(A) |
160 |
|
Welding rated voltage(V) |
26 |
|
Welding current adjustment scope(A) |
50-180 |
|
Welding lasting load rate |
40% |
|
Structure type |
Silent type |
|
Starting system |
Electric starter |
|
Fuel tank capacity(L) |
13.5 |
|
Oil capacity |
1.65 |
|
Noise level(DB) |
110 |
|
Net weight(KG) |
125 |
|
Overall dimension (MM) |
745*505*670 |
