Water Treatment Plant with Ozone Generator and UV Sterilizer

Product Description
1. Drinking Water Treatment System/Equitment( 500-20000LPH)
Water treatment/equitment/plant/system

2. Product description: Our pure or mineral water making line is specially designed for water purifying
.
3. This line includes the following equipment: Mechanical filter, activated carbonfilter, ultraviolet sterilizer, precision filter, positive ion softening device,
Recycling and regenerating device, reverse osmosis device, ozone generator, fiber
Ultra filtering system, etc. We will design the pure or mineral water makingline as per detailed condition of your raw water.


4. Application
The RO water treatment system can purify tap water, underground water, well water, river water and seawater. It has been applied in drinking water, chemicals industry and cosmetic industries etc.

Working Process

1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter

2. Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect.

3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.

4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.

5. Micron filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,

6. High pressure pump-- Provide the high pressure to RO membrane

7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions

model	capacity (T/H)	Working pressure (MPa)	Inlet size(MM)	Membrane  (feet)	Membrane qty	Recovery rate	power (KW)
DT-500L	0.5	1.0-1.4	DN20	40×40	2	50%	1.5
DT-750L	0.75	1.0-1.4	DN25	40×40	3	60%	2.2
DT-1000L	1.0	1.0-1.4	DN25	40×40	4	60%	2.2
DT-1500L	1.5	1.0-1.4	DN25	40×40	6	60%	3.0
DT-2000L	2.0	1.0-1.4	DN25	40×40	8	60%	3.0
DT-250LDP	0.25	1.0-1.4	DN20	40×40	3	50%	2.6
DT-500LDP	0.5	1.0-1.4	DN25	40×40	5	50%	3.7
DT-1000LDP	1.0	1.0-1.4	DN25	40×40	10	60%	5.2
DT-2000LDP	2.0	1.0-1.4	DN25	40×40	16	60%	7.0
DT-2.5	2.5	1.0-1.4	DN32	40×40	10	65%	4.0
DT-3	3.0	1.0-1.4	DN32	40×40	12	65%	4.0
DT-6	6.0	1.0-1.4	DN40	80×40	6	65%	5.5
DT-10	10.0	1.0-1.4	DN50	80×40	10	75%	11
DT-15	15.0	1.0-1.4	DN50	80×40	15	75%	15
DT-20	20.0	1.0-1.4	DN65	80×40	20	75%	18.5



Our Services

(1) We can dispatch our engineer(s) to your side for installing and debugging machines, but our engineer(s) traveling allowances (USD100/day/person), as well as lodging and board expenses, shall be charged at your side.
(2) The machine quality that we sell is guaranteed 1 year.
(3) We shall provide your side spare accessories for easy-damaged parts within warranty year and long
time technical support.

FAQ

Q1:Are you a trading company or a manufacturer?
A1:We have our own factory for many years,can give u best service .

Q2:What's your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 1 year guarantee . we will give u spare part free in 1 year,
Life long after service. Mean while, our engineers go more than 50 countries for debugging, with rich experience.

Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.

Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing
and teaching your technicians how to run the machines.

Q5.What's the delivery time?
A5.30-45 days after the T/T deposit or L/C.

Q6.What's min order quantity?
A6.1 unit
