Product Characteristic:
1. The noise and starting wind speed is low when works, which is specially suitable for small wind areas.
2. It can stand various kind of wind and improve the range of wind utilization
3. Streamlined design, simple structure, running stably, power supply for city lamp, monitoring and home.
4. Large capacity, to be Wind-Solar Hybrid power supply system with solar cells, can meet the need of portable computer, instrument, mobile phones and lighting
5. Blade with the ability of automatically stall protection under strong wind
6. Never need slip ring and the wires would not be convolved.
|
Model |
C-50W |
C-150W |
C-250W |
|
Name |
Wind butterfly |
wind butterfly |
wind futterfly |
|
Rated DC voltage |
DC12V |
DC12V |
DC12V |
|
Rated current |
4.1A |
12.5A |
20A/10A |
|
Rated speed |
220r/m |
178r/m |
165r/m |
|
Max power |
65W |
200W |
300W |
|
Start-up wind speed |
2m/s |
2m/s |
2m/s |
|
Cut-in wind speed |
2.5m/s |
2.5m/s |
2.5m/s |
|
Cut-out wind speed |
18m/s |
18m/s |
18m/s |
|
Rated wind speed |
13m/s |
13m/s |
13m/s |
|
Engine |
Three-phase permanent magnet generator |
ThreeThree-phase permanent magnet gnerator |
Three-phase permanent magnet gnerator |
|
Rotor diameter |
450mm |
600mm |
900mm |
|
Number of blade |
2pcs |
2pcs |
3pcs |
|
Blade material |
FRP(Fiber glass-Reinforced plastics) |
FRP |
FRP |
|
Wind protection |
electromagnetic brake |
electromagnetic brake |
electromagnetic brake |
|
Life Span |
15 year |
15 year |
15 year |
|
Equipment surface protection |
Galvanization plastic coating |
Galvanization plastic coating |
Galvanization plastic coating |
|
Weight |
27kg |
32kg |
37kg |
ShenZhen GREEN ELEC technology Co., Ltd. is a high-tech enterprise which makes commitment to wind powder research, development, production and marking. The company has advanced experiment equipment of wind power and open wind tunnel with diameter of 2.9m. A number of outstanding domestic and international wind power experts makes efforts for the company extraordinary contribution to product development. Company's research results about usage of weak winds, which expand the application scope of wind power generator, have been successfully applied to the field of wind power. ShenZhen GREEN ELEC Technical Co., Ltd, has several domestic and foreign patents. Our products have had the EU CE certification and step into global market with high appraisement.
The company has 50, 000 sets of Wind-solar Hybrid wind turbine production ability and we can supply vertical and horizontal types of products. The company has many distribution agencies, What's more, a large number or agents around the world join our sales.
The company is working on a variety of renewable energy research including sea tide power generating, sea wave power generation, getting water with wind power and power generation at high altitude. We hope to make a brilliant future with friens who are interested in the cause of renewable energy.
We will uphold our corporate philosophy: Creation, Struggle and Return.
The company is eager to work on the struggle for the mankind's survival and development.
