Tw10ss 7kw 3-Cylinder Diesel Generator for Home
| Price: |
US $ 2000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
20/Set |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
Features:
Unparalleled low noise level only about 60~68 dB (A).
*Digital control Panel makes operating and maintaining easier and safer.
*Has compact and humanism design to strengthen the safety of unit.
*Outstanding capabilities and with Auto-warning oil system.
*More comfortable and healthy.
Model No.
| TW10SS
|
Rated Frequency
| HZ
| 50 60
|
Rated Output
| KVA
| 7.5 9.0
|
Max.output
| KVA
| 8.5 10.0
|
Rated Voltage
| V
| 115/230 120/240
|
Rated current
| A
| 65.2/36 75/41.7
|
Rated rotation speed
| rpm
| 1500 1800
|
Phase No.
|
| Single-phase
|
Power factor
|
| 1.0
|
insulation Grade
|
| F
|
Pole number
|
| 4
|
Excitation mode
|
| Brushless Self-excitation constant voltage(AVR)
|
Panel Type
|
| Digital Panel
|
Voltage
| V
| 115/230 120/240
|
Output Receptacle
|
| Two single phase receptacles
|
Connection pole
|
| With
|
DC 12V output
|
| Without
|
Overall dimension:LxWxH
| mm
| 1530x780x1000
|
|
| 1600x830x1120(without wheels&handle)
|
Dry weight
| kg
| 620
|
Working assorting weight
| kg
| 660
|
Noise level 7m
| dB(A)
| 60 63
|
Structure type
|
| Super - Silent
|
Engine Model
|
| SMK385
|
Engine Type
|
| Three-cylinder,Four-stroke,direct injection
|
Cylinder No. Bore x stroke
| mm
| 3-85x90
|
Displacement
| ml
| 1532
|
Rated power
| KW
| 14.0/1500 15.5/1800
|
Combusition ration
|
| 22:1
|
Rated rotation speed
| r/min
| 1500 1800
|
Combustion system
|
| --
|
Cooling System
|
| Water cooled
|
Lubrication system
|
| Pressure splashed
|
Starting system
|
| Electric Starter
|
Fuel type
|
| Diesel 0#(summer,-10#(winter),-35#(Chillness)
|
Lube oil brand
|
| SAE 10W30(above CD grade)
|
Capacity of cooling water
| L
| 7
|
Lube Capacity
| L
| 6
|
Starting Motor capacity
| V-KW
| 12V 1.4KW
|
Charging generator capacity
| V-A
| 12V 20A
|
Battery capacity
| V-Ah
| 12V 60AH
|
Fuel comsuption
| g/KW.h
| 263
|
Fuel tank capacity
| L
| 65
|
Continuous running time
| hr
| 20
|
| Prod Model: |
TW10SS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Output: |
7.5 9.0 |
| Rated Voltage: |
115/230 120/240 |
| Rated Current: |
65.2/36 75/41.7A |
| Rated Rotation Speed: |
1800rpm |
| Power Factor: |
1.0 |
| Type: |
Basic Diesel Generator |
| Installation Method: |
Fixed |
| Stroke: |
Four Stroke |
| Cooling Method: |
Water Cooling |
| Output Type: |
AC Three Phase |
