I.Product introduction:
In order to adapt to the rig modification market needs,we developed 2000 series diesel
engine with higher performance,efficiency,more flexible and better reliability.
2000 series diesel engine is on the basis of Z1V190B diesel engine and
improves more on reliability, economy and power performance, leakage solving
and appearance quality, convenient maintenance, etc. Preferably it can satisfy
the power demand for all kinds of oil drilling, generators, engineering machinery.
2000 series diesel engines can be mated to necessary torque converter unit,
the coupler unit and diesel generator set to use for drive drilling rig or mud pump,
also can be used to fire control, flood control pump, etc.
II Main parameter:
Arrangement of cylinder | 12 ,V type 60°included angle |
Cylinder diameter | 190mm |
stroke | 210mm |
Piston swept volume | 71.45L |
Compression ratio | 14:01 |
Rated speed | 1500 |
Operation manner | Long distance electric control ,hand control |
Starting mode | Gas motor ,electric motor |
Intake mode | Direct injection turbocharging |
lubricating system | Press and plash lubricating |
Discharge temperature | <=600ºC |
Outlet water temperature | <=85ºC |
Oil temperature(oil sump) | <=90ºC |
Oil pressure(kpa) | 392-784 |
Turning(Face output) | Counterclockwise |
Model | Rated power (KW) | Rated speed (r/min) | Specific fuel consumption (g/kw.h) | Oil consumption (g/kw.h) | SIZE L×W×H (mm) | Net weight (kg) |
G12V190ZL | 1000 | 1500 | ≤209.4 | ≤1.6 | 2670×1588×2366 | 5300 |
G12V190ZL-1 | 740 | 1200 | ≤209.4 | ≤1.6 | 2670×1588×2366 | 5300 |
G12V190ZL-2 | 600 | 1000 | ≤209.4 | ≤1.6 | 2670×1588×2366 | 5300 |
G12V190ZL-3 | 810 | 1300 | ≤209.4 | ≤1.6 | 2670×1588×2366 | 5300 |
