Specifications
Hot sales!Slient diesel generator3.0kw 1 Rated power:1-6 2 Home manufacturer 3 Engine speed:300/3600rpm 4 Type:4 cylinder
Hot sales!Slient diesel generator 3kw
Model:2500A/AE
generatingFrequency(HZ):50/60
Max. AC output(KVA):22.2
Rated AC output(KVA):2.22.5
Phasesingle phase
Dc Output:12V/8.3A
Rated AC voltage:110,120,220,230,240,110/220,120/240
engineEngine Model:170F
Engine Type:Air Cooled,4 Stroke,Single Cylinder
ExcitationBrushless Excitation
Voltage RegulatorAVR
Bore X Stroke [mm(in.)]:70X57 (2.76X2.24)
Continuous output (HP):3.43.8
Displacement (CC):219
Engine speed (RPM):30003600
Starting system:Recoil/Electric
Fuel0#(summer) or - 10#(winter) light diesel oil
LubeSAE10W30 (above CC grade)
Fuel tank capacity (L):12
Lubricating Oil Capacity (L):0.8
Fuel consumption rate [(g/kw.h)/r/min]:280/3000288/3600
Continuous Work (h):14
Noise level(at 7m) (DBA):7778
packingN.W/G.W (KG):58/60
Dimension(mm) ( L X W X H ):627X465X537
20ft Container :Qty180
40ft Container: Qty380
1.5 kw single phase slient generator
2. stable power
3. low fuel consumption
4.192pcs load in 20' ' container
5. ISO9001
Rate frequency
|
50 Hz |
Rate Out put power
|
5 kw |
Max output power
|
5.7 kw |
Rated current
|
20.8A |
Rated voltage
|
230 v |
Phase power
|
single phase |
Rated rotation speed
|
3000 r/min |
power factor
|
1 |
DC output
|
12 V/ 8.3A |
engine model
|
TP186FA |
engine type
|
single cylinder. Four stroke. air cooled. direct -injection diesel engine |
Displacement
|
418 cc |
compression ration
|
19: 01 |
Rated power/speed
|
5.7kw /3000 rpm |
start system
|
recoil start and electric start |
SPE fuel consumption
|
≤ 290 g/kw |
Fuel tank capacity
|
16 L |
Lube capacity
|
1.65 L |
Fuel type
|
0# in summer. 10# in winter diesel oil |
Lube grade
|
above SAE10W30 cc grade. |
Structure type
|
Slient |
Dimension (LxWxH)
|
720x470x685 mm |
|
LANDTOP GROUP is specialized in manufacturing and exporting a wide range of electromechanical products, covering Alternators, Generators, Electric Motors, Water Pumps, etc.
With years of development, LANDTOP has developed into a large-scale, modern, comprehensive and international company. Our sales department is located in Fuzhou City (Fuzhou Landtop Co., Ltd. ), a sea-port city, enjoying convenient transportation network. We also have our own factory in Fu'an City (Fu'an Landtop Power Co., Ltd. ). Our international center is located in Hongkong(Hongkong Landtop Group Ltd. ). Our group is equipped with a great number of precise assemble lines, integrated testing systems and checkout equipment. We have professional engineers, skilled QC members, experienced salesmen and the best after-sales services. The current annual export production value is over 15 million US dollars.
We are always making great efforts to achieve the integration of manufacture and sale. We are able to meet our customers' demands, providing them with superior quality products. Our products, owing to reasonable price, high efficiency and energy saving performance, are widely praised by clients in over 80 countries and regions, such as Europe, America, Southeast Asia, the Middle East, Africa, etc.
Professional R&D system, standard technology, a skilled QC team and the best management group can offer you firm guarantee. Our group is continuously making arduous efforts on innovation to better serve our customers. We ensure that our cooperation will bring a win-win benefit to both of us.
