TYPE | Output | Current(A) | Pole Number | Sychronous Speed(r.p.m) |
KVA | KW |
Single phase 230V 50Hz/1500r/min |
ST-2 | 2 | 2 | 8.7 | 4 | 1500 |
ST-3 | 3 | 3 | 13 | 4 | 1500 |
ST-5 | 5 | 5 | 21.8 | 4 | 1500 |
ST-7.5 | 7.5 | 7.5 | 32.6 | 4 | 1500 |
ST-10 | 10 | 10 | 43.3 | 4 | 1500 |
ST-12 | 12 | 12 | 52.2 | 4 | 1500 |
ST-15 | 15 | 15 | 65.3 | 4 | 1500 |
ST-20 | 20 | 20 | 87 | 4 | 1500 |
Three phase 400V 50Hz/1500r/min |
STC-3 | 3 | 3.8 | 5.4 | 4 | 1500 |
STC-5 | 5 | 6.3 | 9 | 4 | 1500 |
STC-7.5 | 7.5 | 9.4 | 13.5 | 4 | 1500 |
STC-10 | 10 | 12.5 | 18.1 | 4 | 1500 |
STC-12 | 12 | 15 | 21.7 | 4 | 1500 |
STC-15 | 15 | 18.8 | 27.1 | 4 | 1500 |
STC-20 | 20 | 25 | 36.1 | 4 | 1500 |
STC-30 | 30 | 37.5 | 54.1 | 4 | 1500 |
STC-40 | 40 | 50 | 72.2 | 4 | 1500 |
STC-50 | 50 | 62.5 | 90.2 | 4 | 1500 |
Place of Origin: Fujian, China (Mainland)
Brand Name: AC Alternator50 kw
Model Number: STC-50
Output Type: AC Single Phase
Speed: 1500/1800RPM
Frequency: 50/60Hz
Rated Power: 50KW
Rated Voltage: 400/230V
Rated Current: 90.2A
AC alternator 50kw
Color: BULE
Power factor: 0.8lagging
Insurance Class: B or C
Protection Class: IP21
Fan material: Plastic or Aluminum
Wire winding: 100% copper
OEM Service: Acceptable
Certificate: CE/ISO9001
Warranty: 1500hours or 1year
The technical performance and mounting dimension of TWG series generator is coincident with
International IEC norm and relevant national standard to fulfil, the quality of which can reach
Up-to-day international level. Main performance index:
1. Four-pole brushless controllable self-exciting, drip-leak-Proof; ( IP21 protect class), class F insulation.
2. Full-damping whole salient construction guarantee generator to operate stably in any condition, and enable it to overspeed running under 150% rated r/p/m.
3. Adjusting rate of stable voltage<± 1%, adjusting rate of instant voltage: -15% ~+20%
4. Wave aberration rate of voltage, harmony wave factor of telephone THF<2.5%, effective factor of telephone TIF<50
Applications This series generator has been extensively utilized as a standby power supply on post
And telecommunication institutes, banks, stock exchange centers, airports, hospitals, hotels,
Commercial building and factories. It can also be applied as a prime power supply for ships,
Mines, and armies as well as highway construction and other rugged environment
The ST series generators are mainly designed to serve as power source of small capacity which supply electricity for lighting purpose in ships as well as for household electric devices used in towns or villages. The generators are excellent in appearance, consolidate in construction and easy to maintain. Dimensions adopt IEC standard. They are suitable for Australia, Europe, America and other countries if the end covers are mabel B.
The generator adopt harmonic wave self-excitation constant voltage system and automatic voltage control excitation constant voltage system, both of them have excellent dynamic characteristic performance, convenient and reliable in operation
