Working Principle
Under certain pressure,with the use of the difference of diffusion rate between nitrogen and oxygen int air on carbon molecular sieve;oxygen molecule ins absorbed largely by the carbon molecular sieve and nitrogen molecule concentrates in gas-phase in a short time,so as to realize separation of oxygen and nitrogen.
Due to the absorption capacity of carbon molecular sieve for oxygen varies largely from different pressure,reducing the pressure can make the carbon molecular sieve release absorbed oxygen molecular and regenerate the carbon molecular sieve,so as to realize repeated recycling of it.
It adopts the technique of two absorption towers,whcih one tower absorbs oxygen and produces nitrogen,while another tower releases the absorbed oxygen and regenerates the carbon molecular sieve.This cyclic-alternating patten can produce high-quality nitrogen continuosly.
Technical Features
Low energy consumption,less cost,strong adaptablity,rapid nitrogen production ande adjustable purity.
Perfect technique process disign and optimal using effect.
Modular strcuture design and saving of floor space.
Convenient operation,stable performace, high atuomation and unattended operation.
Reasonable inner structure,uniform distribution of airflow,reducing of high-speed impacts of the airflow .
Unique protection measure for carbon molecular sieve extends service life of the carbon molecular sieve.
Key parts adopt the famous brand,which is the effective guarantee of the equipment quality.
Automatic venting device with national patented technology ensures quality of produced nitrogen.
It has functions of diagnosis,alarming and automatic troubleshooting for several failures.
Touch-screen display,dew point detection,energy-saving control ,DCS communication,etc.are optional.
Technical parameters
Nitrogen Flow: 5~300Nm³/h
Nitrogen Purity: 95%~99.999%
Absorbent pressure:0.5~1.2MPa
Nitrogen Pressure:0.1~0.7MPa(adjustable)
Nitrogen Dew Point:-40ºC or -60ºC
Model(THN Standard Model)
Output(Nm³/h)
Effective Air Consumption
Air Purification System
Import and Export Caliber(mm)
THN-10A
10
0.5
T-0.5
DN15
DN15
THN-20A
20
0.9
T-1
DN25
DN25
THN-30A
30
1.41
T-1.6
DN25
DN25
THN-40A
40
1.88
T-3
DN32
DN25
THN-60A
60
2.82
T-3
DN32
DN40
THN-80A
80
3.76
T-6
DN40
DN40
THN-100A
100
4.7
T-6
DN40
DN40
THN-120A
120
5.64
T-6
DN40
DN50
THN-150A
150
7.05
T-10
DN50
DN50
THN-200A
200
9.4
T-10
DN50
DN50
THN-300A
300
14.1
T-20
DN65
DN50
THN-400A
400
18.8
T-20
DN65
DN50
THN-600A
600
28.2
T-30
DN80
DN50
THN-800A
800
37.6
T-40
DN100
DN65
THN-1000A
1000
47.0
T-50
DN100
DN80
THN-1200A
1200
56.4
T-60
DN125
DN80
THN-1500A
1500
70.5
T-80
DN150
DN80
THN-2000A
2000
94.0
T-100
DN150
DN80
THN-2500A
2500
117.5
T-120
DN150
DN100
