Heating-V1019 series Electro-thermal Actuator
General
Heating-V 1019 series Electro-thermal Actuator is designed to control the open/close of small valve or Actuating control of PDM of chiller water or hot water for air-conditioning system so as to control the closed loop doublely and steadily.
Characteristics
Paraffin Wax Thurster, PTC heating.
Spring replacement. Valve closed when power off.
No noise.
Travel place and open display.
Technical Data
Power Supply: AC24V, 110V, 230 (220V)
Power Consumption: 2VA
Thrust: 3.5mm
Full Travel Time: 3 ~ 5 mins
Connection Size: M30 x 1.5mm thread
Ambient TemperatureL -5 - 60 degree Celsius
Length of Lead: 900mm
Shell Material: Fire-proof PC (Inner material is Fire-proof PA66 )
Shell Protection Grade: IP54
Applicable
Electro-thermal Actuator is designed to control the open/close of small valve or Actuating control of PDM of chiller water or hot water for air-conditioning system so as to control the closed loop doublely and steadily.
Valve Technical Parameter:
2-way, DN20; Pressure: 1.6Mpa; Liquid temp.: -10-95 degree Celsius
2-way, DN32; Pressure: 1.6Mpa; Liquid temp.: -10-95 degree Celsius
