1) CE, EPA, CERTIFICATION
ISO9001: 2000
2) MOQ: 5 units
3) One year quality warranty
4) Fuel: Diesel, gasoline
5) Frame: Open, silent
6) Power: 5.0/6.0/9.0 KW
For other models, pls feel free to contact us.
|
Frequency |
50 HZ |
60 HZ |
|
Max. AC output |
5.5 KVA |
6.0KVA |
|
Rated AC output |
5.0 KVA |
5.5 KVA |
|
Phase |
Single phase |
|
Insulation() |
F |
|
Rated AC voltage |
115/230, 220, 230, |
110, 120, 110/220, 120/240 |
|
Welding No-load Welding voltage(DC)/() |
60-65V |
|
Rated welding current(DC)/ |
180A |
|
Welding operating voltage(DC)/() |
25-50V |
|
Welding current adjustment scope |
50-210A |
|
Model() |
FD186FA, |
|
Engine Type |
4-stroke single-cylinder with air-cooled |
|
Displacement |
418cc |
|
Compressin ratio |
20: 01 |
|
Engine speed() |
3000rpm |
3600rpm |
|
Starting system |
Recoil / Electric |
|
Fuel tank capacity |
12.5 L |
|
Noise level(at 7m)/(7) |
90 db(A) |
|
N. W()/G. W |
111/ 117KG |
|
Packing Dimension |
720 x 485 x 635 mm |
|
Max power output |
10.0 HP |
