| Price: | US $ 5387/Set |
|---|---|
| Trade Terms: | FOB,CFR,EXW |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,D/P,Western Union,Money Gram |
Rated Power | Genset Model | Electrical Efficiency | Heat Efficiency | Dimensions | Weight |
30kw | BCF30-B | 34% | 48% | 1750×700×1100(mm) | 900kg |
50kw | BCF50-B | 35.5 | 51.3% | 2120×860×1430(mm) | 1200kg |
80kw | BCF80-B | 35.5 | 51.3% | 2460×850×1290(mm) | 1750kg |
100kw | BWF100-B | 33% | 52.6% | 2850×950×1500(mm) | 2100kg |
120kw | BCF120-B | 36% | 52.7% | 2900×1000×1600(mm) | 3050kg |
160kw | BCF160-B | 35.5% | 52% | 2900×1000×1600(mm) | 3245kg |
200kw | BCF200-B | 35.5% | 52% | 3400×1700×1800(mm) | 3850kg |
250kw | BCF250-B | 34.8% | 53.5% | 3450×1750×2100(mm) | 4400kg |
300kw | BHF300-B | 34.8% | 53.5% | 3600×1750×2100(mm) | 4400kg |
400kw | BCF400-B | 36.7% | 52.8% | 4500×1700×2400(mm) | 8200kg |
500kw | BMF500-B | 36.7% | 51% | 5600×2000×2400(mm) | 9100kg |
600kw | BCF600-B | 36.7% | 51% | 5500×2000×2250(mm) | 9800kg |
800kw | BMF800-B | 36.7% | 51% | 5650×2400×2800(mm) | 12500kg |
1000kw | BMF1000-B | 37% | 51% | 5650×2400×2800(mm) | 12500kg |
The optional voltage for above genset:400V;6300V;10500V;35000V | |||||
The Advantage of Binshi Gas Generator Set:
project name | Binshi high quality configuration |
Ignition system | Altronic(import from US) or Kingband ignition system,included spark plug,ignition coil,high-voltage cable ect. |
Speed regulating system | Yunsida,GAC or Kingband electronic governor |
Ignition coil bracket | stainless steel bracket |
Fire barrier | stainless steel materials, four layer resistance warfare, gas pipeline dedicated |
Zero-pressure valve | Imported from Genmany with original packaging, running stably |
Electromagnetic valve | Electrolux, Italy |
Filter | Fio,Italy 3μm filter results |
Gas pressure meter | 50kpa measuring range |
Gas intake pipe(onboard) | Stainless steel material |
Engine | Cummins series,MTU series perkins and Chinese engine ect. |
Water tank | Using domestic famous brand water tank for gas generator re-design and copper material |
Anti-explosion valve | Research and design by Binshi self, explosion-proof effect of market surveillance hundred percent results |
Mixer | Gas mixer or Venturi mixer imported from US |
Undercarriage | Thick steel plate/or box iron |
Control module for genset | Deepsea from UK |
| Prod Model: | BCM35J |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Range: | 20-2000kw |
| Frequency: | 50/60 Hz |
| Power Factor: | 0.8 |
| Warranty: | 1 Year or 3000 Hours |
| Alternator: | Faraday, Leroy Somer, Stamford, Engga Ect. |
| Controller: | Deepsea, Harsen |
| Protection Class: | IP23 |
| Regulator: | AVR |
| Electrical Efficiency: | 36.7% |
| Gas Source: | Gas |
| Power: | 20-2000kw |
