Generator Manufacturers and Factories

Home Generator Products Super Silent Diesel Power Generator Set (30KW)

Super Silent Diesel Power Generator Set (30KW)

Super Silent Diesel Power Generator Set (30KW)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 2/Piece
Pay Type: L/C,T/T,Paypal,Western Union


Silent Diesel Generator Set (30KW)
1. We are manufactory, could give best suggestions to customers.
2. Professional general engineers and technical team.
3. Have spare parts for customers' exchange.
4. Warranty: Running 500 hours or one year.
5.100% copper good brand alternator, every spare parts suppliers are choosed extremely stricted, to control the quality well.
6. From engine to whole genset, we test every link of every product, have test machinery and test center.
7. Many spare parts are produced by ourselves, could save cost for customers greatly.
8. We welcome every customer visiting our factory and test our products.
  WEIFANG HUADONG ENGINE  TACHNICAL DATA
Genset Model GF-40KVA
 Engine Data Engine Model K4100ZD
Engine Type Four stroke,Water-cooled,Direct line,Turbo type
Rated Output 30KW / 37.5KVA
Max. Output 32.4KW / 40KVA
Voltage (V) 380/220
Current (A) 56
Frequency (HZ) 50
Rated RPM (r/min) 1500
Cooling System Forced Water-cooled
Fuel Consumption (≤g/kw.h) ≤258
Compression Ratio 17:01
Bore×Stroke (mm) 100X115
Displacement (L) 3.61
Start Method Electric Start
 Alternator Data Power Factor 0.8 Lag
Insulation Class H
Lubricating System Pressure,Split,Complex
exhaust Air Temperature (ºC) ≤540
Altitude ≤1000m
Environment Temperature (ºC) 40
Connecting Type 3 Phase and 4 Wires,"Y" type connecting
Ignite sequence 1-3-4-2
Intake Type pressurize
Rated Speed Regulation % ≤±1%
Phase 3
Dimension Open Type's Net Weight(kg) 746
Silent Type's Net Weight(kg) 806
Open Type's Dimension Length × Width × Height (mm) 2075×840×1230
Silent Type's Dimension Length × Width × Height (mm) 2100×850×1240
Open Type's 20FT Loading Quantity 6PCS
Silent Type's 20FT Loading Quantity 6PCS
Prod Model: GF2-30KW
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engine: K4100zd
Alternator: Brushless Alternator
Panel: Amf
Cooling Method: Water Cooling
Stroke: Four Stroke
Installation Method: Fixed
Type: Basic Diesel Generator
Output Type: AC Three Phase
Changzhou Hi-earns Mechanical & Electrical Co., Ltd is established in 2005, which is a high-tech(mechanical&electrical) enterprise, gather "development, production, sales and systematic after-sales services" in one. Our company is certified by ISO9001-2008 QMS, get the EPA approval from U. S. A, CE approval from the European Union, GS approval from Germany and RoHS approval. Our company is one of the most influential enterprise in Eastern China, which is in the field of internal combustion engine.

Our company actively introduce advanced foreign technology and scientific management experience. The company have more than 300 staff, 50 of whom are junior and senior technicists, have 6 advanced automatic production lines. In addition, our company adhere to the brand strategy and international strategy, this greatly improved core competitiveness of us. Our main business includes: Water-cooled diesel generator set, air-cooled diesel engine and generator set, gasoline engine and generator set, water pump, minor agriculture machinery and road machinery equipment. Our company have developed out HR170FB which is turbine type air-cooled diesel engine with the own property right. What's more, this product have gained many certification of practical new-type patent. Our newly developed super silent generator set have got certification of invention patent, and we are the only factory which could produce it. Our company have strong technical force, and perfect after-sales service system. Our products have been sold to many main cities in China, and all over the world including North America, European, South America, Southeast Asia, Middle East, Africa, etc.

"Widely making friends with universal heart, positively returning society with responsible mind", this is the aim of Changzhou Hi-earns Mechanical & Electrical Co., Ltd. In the fierce competition environment, we all Hi-earns staff shoulder to shoulder, insist the faith of "surpassing ourself continuously, developing innovation constantly", and continuously strive for being the first brand of domestic and overseas in mechanical & electrical field, this shows Hi-earns unique enterprise charm and grace, which means "sincerity, diligence, cooperation, devotion". We will continue to build enterprise brand sincerely, gain customers' trust with quality, stand on domestic and overseas market with good price, open the future of Hi-earns with strong ability.
