STC series generators are widely used in town, countryside, worksites, mountain and pasture districts as electric power source for lighting purpose, they can also be used as reserved power source for emergency.
The series generators are of drip-poof with rotary field type and adopt harmonic excitation system, easy operation and maintenance.
The generators are ther-phase, four-wire type, adopted star connection with neutral point, The rated line voltage is 400V, phase voltage 230V, frequency 50Hz, power factor 0.8(lag). We can provide 60Hz and other voltage generators according to the customer's request.
They can be coupled with a prime mover directly or through V-belt making right or revese continuous rotation at the rated speed when the revolution slip of prime mover is 3% and load varies within the range of 0100%cosX=0.81.0 they give good constunr voltage.
The generators offer consranr voltage when sudden change(increase or decrease) of load, the generator will soon return to their normal working state in the same time, the generator can directly start an unloaded squirrel cage induction motor without any starting device.
Model
| Power
| Current
(A)
| Poles number
| Speed
(r.p.m)
|
KVA
| KW
|
STC-3
| 3.8
| 3
| 5.4
| 4
| 1500
|
STC-5
| 6.3
| 5
| 9
|
STC-7.5
| 9.4
| 7.5
| 13.5
|
STC-10
| 12.5
| 10
| 18.1
|
STC-12
| 15
| 12
| 21.7
|
STC-15
| 18.8
| 15
| 27.1
|
STC-20
| 25
| 20
| 36.1
|
STC-30
| 37.5
| 30
| 54.1
|
STC-40
| 50
| 40
| 72.2
|
STC-50
| 62.5
| 50
| 90.2
|
Established in 2000, FUAN ZONGCHI MOTOR CO., LTED is a profesional power generation equipment manufacturer, mainly produce generator and generating set.
Manufactory covers 20, 000 square meters, 12, 000 square meters are standard workshop, we have more than 160 staff, and 10 of them are technical personnels.
As a high-tech enterprise, we place great emphasis on quality, We have more than 100 series equipments to support and test our products, such as CAD system, CNC machining equipments, VPI equipment, auto testing system and auto painting lines.
At the same time, we have achieved accreditation to ISO9001: 2000 Systems certificates and boast a number of product certificates, including CE, CCS, CCC and others.
'Zongchi' brand diesel gen-sets have passed the strict technical demonstration. We have a good relationship with CUMMINS, DEUTZ, PERKINS (LOVOL), WEICHAI and chinese famous engine manufacturers. Together with the world famous generator STAMFORD, MARATHON and LEROY SOMER, or our TFW series brushless generator, It uses the lastest intelligent control technical.
Our annual turnover is up to 8 million dollars, with the capacity of 12, 000 sets per years, Our products are exported to more than 30 countries and regions, mainly in Europe, South America, and Middle East.
We warmly welcome every customer to cooperate with us on the basis of mutual benefit, hope to be your faithful friend and best partner.
