Solar Power System 4500W (STS4500)
1. Solar Power System 4500W operating cost is low, almost no maintenance, no spare parts, no additional fuel.
2. Solar Power System 4500W equipment can be run automatically, suitable for use in unattended stations.
3. Solar Power System 4500W does not contain any moving parts, the system can work continuously more than twenty years.
4. Solar Power System 4500W has good modularity, can be customized according to the specific needs of the load current, future expansion.
5. Solar Power System 4500W is very stable DC output voltage.
6. Solar Power System 4500W installation don't need power or road access, it's very easy to be installed in the off-grid area.
Suntotal Group Limited can design solar power system according to your specific requirements, which can provide power for commercial, industrial, and residential purposes.
Solar Panel:
1. CE & RoHS;
2. 90% efficiency in 10 years, 80% in 20 year,
3. >17% efficiency;
4. 25 years life span;
5. 2400PA/m2 impact resistance.
Inverter:
1. Pure sine wave;
2. High convert efficiency with high frequency conversion and PWM technology;
3. Over-voltage and low-voltage protection for battery;
4. Over loading, short circuit, overvoltage and high temperature protection for output;
5. Wrong connection protect for solar panels anode and cathode;
6. Charge and discharge at the same time. Stable output voltage and frequency.
Battery:
1. Colloid Battery;
2. Stable Battery;
3. 7 year spend life.
We can manufacture solar power generating system based on customer's specification and capacity requirement.
|
4500wp Home Solar Power System |
|
Item |
Model |
Power(w) |
Quantity |
Load Power(w) |
Working Hour/day(h) |
Consumption/day(wh) |
|
Light1 |
Energy-saving Lamp |
45 |
3 |
135 |
8 |
1080 |
|
Light2 |
Energy-saving Lamp |
22 |
3 |
66 |
8 |
528 |
|
Light3 |
Energy-saving Lamp |
11 |
3 |
33 |
6 |
198 |
|
Computer |
LED Screen |
100 |
1 |
100 |
8 |
800 |
|
Color TV Set |
29' |
130 |
1 |
130 |
4 |
520 |
|
Refrigerator |
150L |
100 |
1 |
100 |
24 |
2400 |
|
Washing Machine |
|
300 |
1 |
300 |
1 |
300 |
|
Air-condition |
1 P |
1100 |
1 |
1100 |
4 |
4400 |
|
Water Heater |
40L |
1000 |
1 |
1000 |
1 |
1000 |
|
Sum |
|
|
|
2964 |
|
11226 |
|
|
|
|
|
|
|
|
|
|
Configuration |
|
|
Description |
Specification |
QTY |
Price(USD) |
Remark |
|
Solar Panel |
250w, 90% efficiency in 10 years, 80% in 20 year, 25 years life span, 2400pa/m2 impact resistance. |
250w |
18 |
|
User configuration |
|
Integrated Inverter |
High quality pure sine wave inverter, controller and inverter all-in-one. |
216V/6000w/220V |
1 |
|
|
|
Solar Batteries |
Colloid battery, 6 years life span |
12V 150Ah |
36 |
|
|
|
Bracket |
Iron |
|
|
|
User configuration |
|
Cable |
|
|
|
|
|
|
Technic Service |
|
|
Average Capacity of System |
15.6kw |
|
Max Consumption of System |
11.3kw |
|
Warranty |
3 years |
