Features:
Fixed 12V system voltage
Legible display of working mode and battery level
Small, smart and portable
Two DC load output
USB jack for cell phone charging
Can be charge by both solar panel and AC
Degree of protection: IP22
Two working mode
Four stage charge way: Fast, boost, equalization, float
Full automatic electronic protect function
|
Model |
SMB |
|
System voltage |
12V |
|
Max solar current or load current |
2A |
|
Fast charge voltage |
14V(25º C) |
|
Boost voltage |
14.5V(25º C) |
|
Equalization voltage |
14.8V(25º C) |
|
Float voltage |
13.7V(25º C) |
|
LVD voltage |
11.5V,11.8V |
|
LVR voltage |
12.3V,12.6V |
|
Batterytype |
Lead-acid cell |
|
Temperature compensation coefficient |
-4.17mV/K per cell (boost, equalization),-3.33mV/K per cell (float) |
|
Max solar panel voltage |
25V |
|
Max battery protect voltage |
15.5V |
|
Own consumption |
5mA |
|
Dimension |
215X75X160mm |
|
Ambient temperature |
-20~+50º C |
|
Degree of protection |
IP22 |
|
Max altitude |
4000m |
Nanjing Putian Datang Information Electronics Co., Ltd. Establish in 2005, is a branch company of Nanjing Putian Telecommunications Co., Ltd which has come to the stock market in Hongkong Stock Exchange Market in 1997.
The company mainly manufactures all sorts of solar controller, LED constant current drive and wine wave inverters. With waterproof design, advanced technology, powerful functions and reliable quality, the products can adapt to various harsh environments and are well received by customers at home and abroad.
Nanjing Putian Datang Information Electronics Co., Ltd. Possesses more than 10, 000 square meters standardized electronic plants. The company has certified by ISO and CE.
