Brand Name SNH CABLE
Model Number PV1-F
Type Insulated
Application Solar photovoltaic system circuit connection
Conductor Material Copper
Conductor Type Stranded
Insulation Material XLPE
Votage rating 600/1000V
Conductor Class 5 flexible plain copper
Conductor material Tinned anaerobic electrolytic copper
Insulation 120c XLPE, Black
Sheath 120c XLPE, Black
Work environment temperature rating -40 to 90c
Application indoor and outdoor solar photovoltaic system connection
Bending radius 4*D
1. The rated voltage: 600/1000 V temperature: 120 ° C
2. The product structure:
(1) conductor: Tinned anaerobic electrolytic copper
(2) insulation: 120 ° C XLPE, black
(3) jacket: 120 ° C XLPE, black
3. Applications
This product is suitable for extreme weather conditions, the indoor and outdoor solar photovoltaic system circuit connection.
4. Product performance
Photovoltaic system special cable the use of advanced radiation crosslinking technology, adopt low smoke, halogen-free flame retardant materials production electric wire. Excellent resistance to high temperature and UV radiation, ozone resistance, resistance to water vapour, antimicrobial, short-term overload ability, long service life, wear-resisting, oil resistance, corrosion resistance, high tensile sex, etc.
Shanghai Nanhui cable Co., Ltd. (SNH CABLE) is a professional Manufacture, who engages in electrical Cables and Wires manufacture. SNH CABLE has established for 20 years since 1984, our location is No. 15 Gu Ai Road, Xinchang Town, Pudong area, Shanghai, only 25 KM far from Shanghai Pudong International airport.
Our factory covers an area of 25000 square meters and has about 300 employees including 10 high-educational technicians.
Our main products: AAC, ACSR, XLPE cable, HO1N2-D, H07RN-F, H05RN-F, common rubber cable, EPR cable, mining cables, power cables, welding cables, marine cable, etc.
Furthermore, we can also produce the definite cables base on customers individual requirements, such as the cables with different metal conductor (e. G. Cu. Al. CCA. CCS, etc. ), with various materials insulation and Jacket (e. G. PVC, XLPE, RUBBER, PE, etc. ), and with different type of armor (e. G. SWA, STA etc. ).
Our certification: CCC, IEC, MA, TUV Rheinland, ISO. Safety certificate of approval for mining products, China classification society certificate with guaranteeing stable and timely supply, credible quality and sincere service, SNH CABLE has own sound fame both in domestic and oversea market, and has been successfully sold all over the world more than 40 countries, and its production amount has been up to billion dollars annually, since 2004.
In order to reward the supporting by customers and friends, SNH CABLE will and would provide you cables with high quality and efficiency!
