Home Generator Products Small Wind Power Generator 3000W for Home

Small Wind Power Generator 3000W for Home

Small Wind Power Generator 3000W for Home
Price: US $ 3800/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
Product Features of 3kW wind turbine:

1) Smart control by PLC controller
Hummer 3000W wind generator's controlling system adopts the smart touch-screen PLC (Programmable Logic Controller) which is integrated with Siemens controlling unit. The PLC will alarm and adjust the abnormal running status of the wind turbine automatically both timely and efficiently. Siemens module offers high reliability to our PLC and its customers worldwide can testify for that.

2) Low noise
The design of the rotor blade of Hummer 3000W wind generator absorbs the highlights of the small aircraft's airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.

3) Triple braking protection from over winds
Hummer 3kW wind turbine generally adopts the yawing system and the electromagnetic braking system to regulate the rotation of the wind turbine. Besides, customer can order the hydraulic braking system as well as a third protection. It is easy and convenient to shut down the whole system both manually and automatically.

Application of 3kW wind turbine:

1) Housing, office, farm and factory;
2) Telecommunications Station
3) TV Transfer Station;
4) Monitoring Station (military, hydrology, observatory)
5) Water-pumping Station;

Product Range:

1) 500W-100kW wind turbine Off-grid /Grid-tied;
2) 400W-600W Wind-Solar LED street light and traffic light;
3) Wind-Solar hybrid generating system.
4) Wind-Solar-Diesel hybrid generating system.
Model No. H4.8-3KW
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter 4.8m
 Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 3kW @ 10m/s
Battery Bank Voltage 48V to 180V
System Output Voltage 110/220Vac single phase
Cut-in Wind Speed 2.5m/s
Rated rotating rate 265 r/min
Working Wind Speed 3-25 m/s
Survival Wind Speed 50 m/s
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 81.7kg
Energy monitoring & User control Siemens PLC controller with touch screen
Gearbox None, Direct drive with front generator design
Over Speed Regulation Auto Yawing & Hydraulic Braking
Shutting Down Method Manual & Automatic electromagnetism Braking
 Warranty  2 years

Prod Model: H4.6-3KW
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Generator Type: Permanent Magnet Generator
Certificate: CE, BV, ISO
Start-up Wind Speed: 2.5m/S
Working Wind Speed: 3-25m/S
Over Wind Speed Control: Electromagnetism Brake, Yawing
Survival Wind Speed: 50m/S
Rotor Blade Material: Fiber Glass
Generator Weight: 71.8kg
Output Voltage: 110V to 240V Single Phase
Battery Bank Voltage: 48V to 180V
Rotating Shaft: Horizontal
Number Of Blade: Three Blade
Stress Way Of Blade: Resistance
Anhui Hummer Dynamo Co., Ltd. is a professional wind generators manufacturer with high-tech in the field of wind energy.

We specialize in researching, developing, producing and promoting of small-sized wind generator system, and also provide solutions for setting up small-scaled wind farm. After nearly 30 years efforts, our company has developed independent intellectual property rights of "Hummer" wind generator and control system.

There are more than 200 employees in the company including 40 R&D staff. And the factory covers over 30, 000 square meters with the workshop more than 7.5 Acres. There are more than 100 sets of large machines for processing, cutting and spray-painting equipments, and also many testing and examining systems. The monthly output is 3, 000 sets.

All Hummer small-sized wind generators including wind generator from 400W to 200KW, which have acquired CE certificate. Meanwhile, Hummer' S wind generator with good reputation can be found in more than 91 countries and regions, such as EU, North America, Oceania, Africa and Asia.

Hummer' S wind generators have the features of "Super Light, Small, Swift and High efficiency" when comparing with traditional' S. We have a powerful R&D team (consisting of experts enjoying government allowance), providing a reliable strength for product upgrade& technical support. The management team has abundant experiences in production, marketing, service and consultation. Until now our company has formed a comprehensive management system of research, study, development and service.

Hummer aims to be a worldwide influential enterprise as well as the best domestic manufacturer and service provider.
