Wind Power Generation
1. Start in breeze 3.5m/s
2. High efficient Output
3. CE ISO
Products Range: 100W~2mW
(1). Dual, automatic emergency braking system
(2). Sealed Sweden SKF bearing
(3). Waterproofing
(4). Unique Anti-Vibration design
(5). Efficient Aero-dynamic design
(6). High strength, corrosion resisting aluminium alloy
(7). Unique neodymium iron boron permanent magnetic material
(8). Low noise level
|
Model |
NL-500M |
NL-600M |
NL-800M |
|
Rated power |
500W |
600W |
800W |
|
Max power |
550W |
650W |
850W |
|
Rated voltage |
24V/48V |
24V/48V |
24V/48V |
|
Starting up speed |
2.5m/s |
2.5m/s |
2.5m/s |
|
Host Net |
7kg |
7.5kg |
8kg |
|
Rated revolution |
600 r/m |
600 r/m |
600 r/m |
|
Blade diameter |
1.8m |
1.8m |
1.9m |
|
Host weight |
15kg |
15.2kg |
16kg |
|
Size mm (stator H x stator φx Shaft L) |
100*175*60mm(Single shaft)
100*175*205mm(Biaxial) |
|
Blade number |
3 |
|
Blade material |
Nylon fiber /carbon |
|
Tower height |
6m |
|
Generator |
3-phase ac permanent magnet synchronous generator |
|
Brake |
electromagnetic brake/partial side |
|
Speed adjustment mode |
According the wind direction , Automatic adjust the Angle |
|
Temperature |
-40°C to 80°C |
Shanghai Noulei Automation Equipment Company Limited mainly produces wind turbines, with engraving machine and injection machine as extension product.
Our company owns professional engineers, advanced equipment and testing facilities and after service systems.
Our products occupy the domestic market and are exported to the United States, France, Canada, Norway, Australia and so on, which are well received and popular among these countries.
The wind turbine R&D has a complete independent power supply system in any weather conditions with protective system, simple operation and easy maintenance.
