FEATURES
Micro-processor based design;
Meter two 3-phase AC Voltages;
Configurable priority of supply Able to Set I# supply priority or II# supply priority or NONE supply
Priority;
Set AUTO or MANUAL via PUSHBOTTON mounted on the front panel;
Two isolable N designed;
6 LEDs display the status;
Operational timers can be altered by the customer;
Control generator to Start;
SPECIFICATION
AC supply: 180 to 260 V (50/60Hz) 1.5VA
Under voltage: 265± 5 V, Under voltage: 172± 5 V.
3-phase AC input: 0 to 460V 50Hz(3 phase)
Relay output:
Relay of close O&I&II: 3A 230VAC
Relay of start genset: 7A 230VAC(Normal Closed, volts free)
Delay timers:
Normal delay time: 1~60s
Abnormal delay time: 1~60s
Start generator time: 1~60s(after road I is abnormal)
Stop generator time: 1~60s(after road I is normal)
Operating Temperature Range: -30 to +70° C
