Company operation principles
1. Gasoline generator with high quality and competitive price
Provide the best quality products and nice price to customers
2. Frank and honest
Frankly and honestly treat to all the customers
3. Respect people
Respect every person anywhere, anytime
4. Seek excellence
Produce top quality products, provide good service, employ excellent people, ensure the efficient operation and development of company.
|
Product |
Gasoline generators |
Gasoline generators |
Gasoline generators |
|
Place of Origin |
CHONGQING CHINA |
CHONGQING CHINA |
CHONGQING CHINA |
|
Brand Name |
ZHAOTIAN POWER |
ZHAOTIAN POWER |
ZHAOTIAN POWER |
|
Model |
ZTQF2500 |
ZTQF2500 AVR3 |
ZTQF3000 |
|
|
|
|
|
|
Genset Type |
Single-phase |
Single-phase |
Single-phase |
|
AC Frequency (HZ) |
50 |
50 |
50 |
|
AC Voltage (V) |
220V |
220V |
220V |
|
Cont. AC Output (KW) |
2.0KW |
2.0KW |
2.5KW |
|
Max. AC Output (KW) |
2.2KW |
2.2KW |
2.8KW |
|
Rated currenct(A) |
9 |
9 |
11 |
|
Max. current(A) |
10 |
10 |
12.5 |
|
|
|
|
|
|
Engine Model |
ZT170F |
ZT170F |
ZT170F |
|
Power Factor (COS) |
1.0 |
1.0 |
1.0 |
|
Bore*Stroke (mm) |
70*54 |
70*54 |
70*54 |
|
Engine Type |
Air Cooled, 4 Stroke, OHV Gasoline, Single Cylinder |
Air Cooled, 4 Stroke, OHV Gasoline, Single Cylinder |
Air Cooled, 4 Stroke, OHV Gasoline, Single Cylinder |
|
Displacement (CC) |
210 |
210 |
210 |
|
Engine Speed (RPM) |
3000 |
3000 |
3000 |
|
Starting System |
Handle Recoil start |
Handle Recoil start |
Handle Recoil start |
|
Max. Power Output (HP) |
7.0HP |
7.0HP |
7.0HP |
|
Fuel Tank Capacity (L) |
15L |
15L |
15L |
|
Cont. Operating (HRS) |
10h |
10h |
10h |
|
Operating Noise Level (dB) |
68dB |
68dB |
68dB |
|
Automatic circuit protection device |
Y |
Y |
Y |
|
Engine oil level warning alarm |
Y |
|
|
|
Automatic Voltage Regulation |
|
Y |
Y |
|
Benefits |
1. Rubber shock absorber at the back of the motor, effective protection from transport damage |
1. Rubber shock absorber at the back of the motor, effective protection from transport damage |
1. Rubber shock absorber at the back of the motor, effective protection from transport damage |
|
2. Gasoline type and volume clearly marked on the tank cup |
2. Gasoline type and volume clearly marked on the tank cup |
2. Gasoline type and volume clearly marked on the tank cup |
|
3. Stable and long continue work capability |
3. Orange shield with round panel |
3. Engine oil alram, automatic shutdown when oil error detected |
|
|
4. Special luminous panel design for night work |
4. Red shield |
|
|
5. Engine oil alram, automatic oil error shutdown |
5. Stable and long continue work capability |
|
|
6. Stable and long continue work capability |
|
|
|
|
|
|
|
|
|
|
|
Packaging Details |
Carton Packing |
Carton Packing |
Carton Packing |
|
Gross Weight (KG/SET) |
41 |
41 |
42 |
|
Carton Dimension (MM) |
595*445*460 |
595*445*460 |
595*445*460 |
|
20' GP/40' GP/40HQ(Set) |
144/316/395 |
144/316/395 |
144/316/395 |
|
Minimum Order Quantity |
Negotiable Trial Order |
Negotiable Trial Order |
Negotiable Trial Order |
|
Delivery Time |
1 week |
1 week |
1 week |
|
Payment Terms |
T/T in Advance |
T/T in Advance |
T/T in Advance |
|
Supply Ability |
400Pcs/Day |
400Pcs/Day |
400Pcs/Day |
Chongqing Zhao Tian Power Machinery Manufacturing Co., Ltd. was established in September, 2009. We are a professional and leading-positioned manufacturer of gasoline engines, gasoline portable generators, gasoline water pumps, tillers and other agricultural machinery. We are located in Chongqing of China, with convenient transportation access. All our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
Now we have over 80 employees, boast an annual sales figure that exceeds USD20million and are currently exporting 30% of our products to overseas markets.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Besides, we have received ISO9001: 2000 certification.
As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Central Asia, Southeast Asia, East Europe and Africa.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
