1. Permanent magnet
2. Sine wave
3. High sensitive&low noise
4. Lagre power, widly usage
5. CE&RoHS
Detailed Description
Adopt high-quality and high-strength permanent materials to ensure high energy conversion efficiency.
Adopt high-quality and high-strength aluminum alloy to make the unit light weight and easy installation.
The fiber-glass blades have the advantages of great intensity and excellent fatigue resistance.
Stainless steel shaft and screws to avoid rust and corrosion.
And the surface is coated with pollution-free material. Working environmental temperature from -20C-50C.
Electromagnetic brake is with the function of over-speed and over-current protection.
About windturbine&windmill
A wind turbine is a device that converts kinetic energy from the wind, also called wind energy, into mechanical energy; A process known as wind power. If the mechanical energy is used to produce electricity, the device may be called wind turbine or wind power plant. If the mechanical energy is used to drive machinery, such as for grinding grain or pumping water, the device is called a windmill or wind pump. Similarly, it may be called wind charger when it is used to charge batteries.
Today's wind turbines are manufactured in a wide range of vertical and horizontal axis types. The smallest turbines are used for applications such as battery charging or auxiliary power on boats; While large grid-connected arrays of turbines are becoming an increasingly important source of wind power-produced commercial electricity.
|
Model |
FD6.4-5000 |
|
Rated power(W) |
5000 |
|
Rated voltage (DCV) |
240 |
|
Rotor diameter(M) |
6.4 |
|
Start-up wind speed(m/s) |
2.5 |
|
cut-out wind speed(m/s) |
16 |
|
Rated wind speed |
10 |
|
Security wind speed(m/s) |
45 |
|
Yaw mode |
hydraulic pressure |
|
Rated rotating rate |
200 |
|
Blade material |
Reinforced fiber glass |
Blade quantity |
3 |
Guy cable
tower |
Tower height |
|
|
Tower thickness(mm) |
6 |
|
Tower diameter |
273 |
|
Free stand tower and hydraulic tower |
Tower height |
12 |
|
Matched inverter type |
sine wave |
Shanghai Saipwell Electric Co., Ltd. is a subordinate of saip electric group company limited, which is wholly invested by our group company. Depending on our group company's advanced technology and equipment introduced form developed countries, we have tremendous technical capabilities. Buondi mainly develops and produces thermostats, heaters, hiboxes and all kinds of waterproof enclosures, solar charge controller, solar generator, wind generator etc.
