Diesel generator set
GP series diesel generator set specification:
1. Engine: Import Perkins
2. Alternator: Meccalte, Leroy Somer, Stamford, or Marathon
3. Rated Voltage: 230V, 400V, 440V, 480V
Voltage available:
50Hz: 200/115, 220/127, 220/110, 230/115, 240/120, 380/220, 400/230, 415/240(200V--690V)
60Hz: 480//277, 440/254, 220/127, 240/139, 208/120, 120/240V
4. Power range: 7KW - 1800KW (9kVA-2250kVA)
5. Rated Frequency: 50Hz
6. Rated Speed: 400V/1500RPM
7. Excitation way: Brushless Excitation
8. Inspiration method: Natural aspirated or turbocharged
9. Cooling Method: Water-cooled
10. Governor Method: Electrical or Mechanical governor
11. Cylinder: 3L-16V
12. Phase: 3pH-D / 3pH-C/F
13. Protection: IP23
14. Insulation Class: H
15. Stroke: 4 Stroke
16.8 hours operation tank /or no tank
17. Key start/Auto start
18. Soundproof / weather-proof canopy is optional
19. Filter system: Oil, fuel and air filter
20. Accessories: Exhaust elbow, bellow, muffler
21. Supply standard collocation:
A)Diesel engine with all accessories, 3 filter, electric systems
B)Alternator
C)Steel structure
D)Fan and water tank cooling system
E)Flange connector
F)12/24 V starting motor and charge engine
G)Air cleaner, fuel cleaner, oil cleaner
H)On-board control panel
I)MCCB air conservation switch
J)12/24V starting accumulator and Battery line
K)Set shock absorber
L)High-efficient silencerlnner
22. AMF, ATS, Soundproof canopy and movabel trailers for choices.
23. Standard: CE and ISO9000, ISO14000
24. Standard export packaging or as customers requirement
With long production experience in mini engines and pumps, Taizhou Yangchun Electric Motor Co., Ltd, is a provincial professional manufacturer integrating design, production, sales and service together. By now, we possess consummate automatic computerized detecting lines for pumps and engines, full-automatic static painting assembly lines, advanced engine and pump making and assembly lines for producing various "Yangchun" branded pure water pumps, immersing pumps, engines, air compressors and generators.
The development of our company depends on complete specifications, various varieties, advanced designs, refined materials, advanced technologies, excellent performance, reliable applications and durability. Our products are exported to Southeast Asia and win a good reputation among abroad and domestic customers. Our well-known production scales have been developing constantly based on the advantages of advanced technique, considerate marketing service and favorable prices.
We sincerely hope to establish permanent and cooperative relationships with customers all over the world based on mutual benefits. Please feel free to contact us for further information. Any investment or inquiry is appreciated.
