Silent Diesel Generator Set Power by Quanchai
Rate power: 10-40KVA
Voltage: 230/400v (110-760v)
Frequency: 50(60Hz)
1. Quanchai diesel engine:
2. Alternator: SLG or STG series Brushless Alternator
Standard parts: Meter. DieselFuel tank. Digital controller etc
3. Optional parts: ATS
|
Technical Data |
|
|
|
|
Type |
DG-10 |
DG-20 |
DG-30 |
DG-40 |
|
Rated Power(KVA) |
10 |
20 |
30 |
40 |
|
QC Diesel Engine |
Type |
QC380D |
N485D |
4102D |
4105D |
|
cylinder no. |
3L |
4L |
4L |
4L |
|
Diesel-Consumption (g/kw. h) |
< 237 |
< 237 |
< 237 |
< 237 |
|
Bor*stroke(mm) |
80*90 |
85*90 |
100*105 |
100*105 |
|
Starting systerm |
Electric Starting |
Electric Starting |
Electric Starting |
Electric Starting |
|
cooling Mode |
Closed Circulation Water Cooling |
|
Brushless Alternator |
Type |
MIC-10 |
MIC-20 |
MIC-30 |
MIC-40 |
|
Rated Power(Kva) |
10 |
20 |
30 |
40 |
|
Characteristic |
Stamford model. Brushless Self excitation. With AVR |
|
Rated Voltage(V) |
230/400V |
|
Rated Freq. (Hz) |
50HZ |
|
Rated Speed(r/min) |
1500RPM |
|
Genset |
Standar parts: |
with meter. indicator, Emergency stop switch. with battery and Diesel fuel tank |
|
|
Additional Parts |
Digital Controller panel |
|
Open Genset |
Dimensions(LxWxH)mm |
1600*700*900 |
1700*700*900 |
1900*700*900 |
1900*700*900 |
|
Weight(kgs) |
550 |
700 |
800 |
900 |
|
Silent Genset |
Dimensions(LxWxH)mm |
1660x880x950 |
1830x880x950 |
2000x900x1040 |
2000x900x1040 |
|
Weight(kgs) |
650 |
800 |
950 |
950 |
