Silent Diesel Generator
Engine model: Perkins(Lovol) - 1006TG1A or other engine Model
Alternator: Leroy Somer
Rated power (Kw/KVA): 56/70
Voltage (V): 400/230
Current (A): 180
Frequency (Hz): 50Hz or 60Hz for option
Power factor: 0.8(lagging)
Excitation mode: Brushless self-excitatioN
Phase/Connection: 3-phase; 4-wire; Y type connection
Voltage regulation rated: ≤ ± 1%
Voltage Regulation: Automatic
Insulation grade: H
Engine type: 6-cylinder, 4-stroke, water cooled, Turbocharge
Air Intaking method: Turbocharged, intercooled
Bore x stroke (mm): 4-100× 127
Displacement (L): 6.25
Fuel consumption rate(g/kW. H): ≤ 205
Continuous running time (H): ≥ 8
Noise: ≤ 75dBA
Starting system: 24V Electric starter
Dimension(mm): 2100x750x1350
Weight(kg): 940
Certificates: ISO: 9001, EPA, CE
MOQ: 1 Set
Delivery time: 25 days
Payment terms: T/T; L/C at sight.
