Alternator-Type Revolving field type 2pole generator
Frequency (Hz): 50 60 50 60 50 60
Rated output(kW): 2.8 3.3 4.2 4.5 4.5 5.0
Voltage(A. C)(V): 230 240/120 230 240/120 230 240/120
DC output(A. C)(V-A): 12.2 13.8/27.5 18.3 20.8/41.7 20 20.7/43.4
Engine speed(r/min): 3000 3600 3000 3600 3000 3600
Power factor(% ): 1
Excitation System Controlled Constant Operation
D. C output V/A: 12V/8.3A
Coupling Pattern Straight Shaft Coupling
Engine Model: 178FGE 186FGE 186FAGE
TYPE Direct injection Vertical, 4cycle, air cooled diesel engine
Displacement cc(cu. In): 296(18.06) 406(24.78)
Rated Output(kw/rpm): 3.7 4.0 5.7 6.3 5.7 6.3
Max. Output(kw/rpm): 4.0 4.4 6.3 6.8 6.3 6.8
Starting system Recoil start
Governor system Centrifugal weight system
Fuel tank capacity(L): 13.5 16
Lube oil capacity(L): 1.1 1.65
BorexStroke(mm): 78x62 86x70 86x72
Protection system CX: Low oil, warning system/stop device
Dim LxWxH(mm): 850x520x730 920x520x730
N. W. (kg): 126 175
Noise level at 7m dBA: 78 78
We would like to introduce ourselves as a leading manufacturer of gasoline engine, generator sets, centrifugal water pump, dirt water pump, high pressure fire fighting pump, welding & generator set, which pass EPA, CE, GS, TUV and ISO 9002 attestation and have been exported to over 80 countries and regions, including USA, Canada, Germany, Italy, etc.
