Silent 600kw cummins electric power generator for sale
1. Cummins+Leroy Somer, Stamford
2. Smartgen, deepsea, Comap control
3.1000 running hours warrrant
General Configuration
1) Based Frame with 8 hours Fuel Tank.
2) AOSIF Control panel with Smartgen6110 control module
3) Two pieces of 120 AH battery
4) Set mounted Copper Radiator
5) High quality main circuit breaker.
6) Optional AOSIF soundproof/waterproof canopy and movable trailer
Accessory: Exhaust silencer, Flexible pipes, flange, Battery wires, Battery charger Float battery charger, AVR, Wires diagram, manual books.
We can also supply the Stamford, Marathon and Kaijieli alternator, you can choose you like.
Control System:
1. Protection: Automatic start/stop, load transfer and alarming of generator;
2. Three channel analog inputs, may joint with Resistive-type temperature/ pressure/ fuel level
3. Sensors, Several temperature and pressure sensors can be used directly (ie. VDO, DATCON, CUMMINS), also may select "user defined" sensor via entering 8 point curves;
4. Display of generator cumulated electric energy;
5. Security password-protected programming levels.
6. Several crank success conditions are optional;
7. Power supply range is wide, accommodating to different starting battery voltage environments;
8. All parameters use digital modulation, abandoning analog modulation using conventional electronic potentiometer, reliability and stability are increased;
9. Built-in watch dog can never be dead halt, ensuring smooth program execution;
Genset Model |
AC825 |
Prime Power(50HZ) |
600KW / 750KVA |
Standby Power(50HZ) |
660KW / 825KVA |
Frequency/Speed |
50Hz/1500rpm |
Standard Voltage |
230V/400V |
Voltage Available |
220V/380V |
Phases |
Three phases, four wires |
Manufacturer |
Xiamen AOSIF Engineering LTD. |
Manufacturer |
Chongqing Cummins Engine Co. Ltd. |
Model |
KTA38-G2 |
Engine speed |
1500rpm |
Engine power |
|
--------------------Standby power |
731kw /980HP |
--------------------Prime power |
664kw /890HP |
Type |
4 cycle, 60 ° Vee; 12-cylinder |
Aspiration |
Turbocharged and Aftercooled |
Governor |
electrical |
Bore * Stroke |
159*159 mm |
Displacement |
37.8 L |
Compression ratio |
14.5:1 |
Idle speed |
725 – 775 r/min |
Brake mean effective pressure |
1407- 1551kPa(prime power-standby power) |
Piston speed |
7.9 m/s |
Friction horsepower |
86kw(115HP) |
Model |
LSA49.1 M65 |
Output power |
600KW |
AVR model |
R450 |
Number of phase |
3 |
Power factor (Cos Phi) |
0.8 |
Altitude |
≤ 1000 m |
Overspeed |
2250RPM |
Number of Pole |
4 |
Exciter type |
AREP |
Insulation class |
H |
Voltage regulation |
±0.5% |
Sustained short circuit current |
300% (3 IN) : 10s |
Total harmonics (TGH/THC) |
< 4 % |
Wave form : NEMA = TIF |
< 50 |
Wave form : I.E.C. = THF |
< 2% |
Bearing |
single |
Coupling |
Direct |
We, Xiamen AOSIF Engineering Ltd is one of generator manufacturers founded in 2001, we dedicated ourselves to the production, R & D and maintenance of various diesel generator sets, electrical control systems, and related accessories like soundproof canopy, Trailer, ect.
We always submit ourselves to cooperate with international and domestic manufactures of diesel engine and have earned good recognition and reputation from our customers due to our quality orientation under ISO9001, ISO14001, CE, SGS, Soncap Certifications and OEM Partners of Cummins, Wandi, Jichai and Leroy-somer as well, which were certified one after another since 2003.
Nowadays we have our own registered trademark "AOSIF" to be well known of all customers worldwide who have always been in business on power, and our generator sets have been exported to more than 50 countries, which focus on Asian, European, African and American. Our mission is to advance our scientific management, to improve our quality level constantly and to maximum customers' profitability.
We have manufactured many kinds of products as below,
Engine brand: Cummins, Perkins, Deutz, Doosan, Volvo, Johndeere, Man, Mitsubishi, Lovol, and Chinese local brands etc...
Alternator brand: Leroy somer, Stamford, Marathon
Power range: 5kVA-5000kVA
Delivery time: 15 to 30 days.
Quality Warranty Period: 1 year or 1000hours whichever comes first
Customers satisfaction is the aim of our team!
