1. Marine diesel generator set diesel SF Overview
Marine diesel generator sets, compact structure, reliable operation, power is strong, good economic and technical indicators, emission targets, advanced, start fast, simple operation, easy maintenance. Products are widely used fishing vessel, passenger vessel traffic transport, inland shipping, port tugs, ship construction, law enforcement boats, military auxiliary vessels, marine generator sets, generator sets land use, types of power plants and pumping units.
2, SF marine diesel generator set diesel engine shut down SF diesel engine marine diesel generator set before running off to be idle for 3 to 5 minutes to allow oil and coolant into the combustion chamber, bearing away the heat and friction, especially in the supercharged and turbocharged engine, is particularly important.
3, SF marine diesel generator set diesel engine operating precautions A, to avoid the coolant is lower than 60 degree or higher than 100 degree the case of continuous operation of the engine as soon as possible find out why. B, prohibit the operation of the engine oil pressure is too low. C, the engine in full throttle, maximum torque speed of the running time must not exceed 30 seconds.
4, SF marine diesel generator set diesel coolant filling A, filling the coolant, do not too fast, otherwise, the engine is cold sets in the gas discharge is not easy, this will cause the engine running temperature is too high. B, to fill the coolant, the engine shut down after the heat check, until the fill up. C, if the engine is water-cooled intercooler, filling coolant must open the release valve on the water.
|
Unit parameters |
Engine Parameters |
Generator parameters |
|
400V/1500rpm/50Hz |
Engine Parameters Starting way: electric start Cooling: Unit with Sea water heat exchange |
Brushless, self-excitation, AVR, three-phase three-wire |
|
type |
Rated Power |
Rated Currency |
Engine Type |
Power |
Bore / Stroke |
Type |
Fuel consumption |
Generator Type |
Rated Power |
|
kw |
A |
kw |
mm |
g/kw. h |
kw |
|
CCFJ-40J-Y |
40 |
72 |
4135Caf |
59 |
135/140 |
Lnline four-cylinder |
232 |
TFXW-225M4-H |
40 |
|
CCFJ-50J-Y |
50 |
90 |
4135Caf |
59 |
135/140 |
232 |
TFXW-225M4-H |
50 |
|
CCFJ-64J-Y |
64 |
115.2 |
4135ACaf |
74 |
135/150 |
232 |
TFXW-250M4-H |
64 |
|
CCFJ-75J-Y |
75 |
135 |
6135Caf |
88 |
135/140 |
Lnline six-cylinder |
230 |
TFXW-250M4-H |
75 |
|
CCFJ-90J-Y |
90 |
162 |
6135ACaf |
110 |
135/150 |
230 |
TFXW-250M4-H |
90 |
|
CCFJ-120J-Y |
120 |
216 |
6135ZCaf |
140 |
135/140 |
Inline six-cylinder, turbocharge |
232 |
TFXW-250L4-H |
120 |
|
CCFJ-150J-Y |
150 |
270 |
NT6135ZC |
191 |
135/160 |
224 |
TFXW-315M4-H |
150 |
|
CCFJ-180J-Y |
180 |
324 |
NT6135ZL |
220 |
135/168 |
Inline six-cylinder, turbocharged |
215 |
TFXW-315M4-H |
180 |
|
CCFJ-200J-Y |
200 |
360 |
8138ZLCz |
294 |
135/163 |
Inline eight-cylinder, turbocharged |
215 |
TFXW-315M4-H |
200 |
|
CCFJ-250J-Y |
250 |
450 |
8138ZLCz |
294 |
135/163 |
215 |
TFXW-315L4-H |
250 |
