| Price: | US $ 7500/Set |
|---|---|
| Trade Terms: | FOB,CIF,others |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
| Model | Length | Width | Height |
| CCFJ40 | 1680 | 730 | 1150 |
| CCFJ50 | 1680 | 730 | 1150 |
| CCFJ65 | 1680 | 730 | 1150 |
| CCFJ80 | 1680 | 760 | 1180 |
| CCFJ100 | 1800 | 760 | 1180 |
| CCFJ120 | 2050 | 785 | 1300 |
| CCFJ140 | 2150 | 785 | 1300 |
| UNIT :mm | |||
|
Genset Model |
Engine Model |
Rated Power (kW) |
Fuel Consumption at Rated Power (L/hr) |
Genset Rated & Standby Output (kW / kVA) |
Genset Frequency (Hz) |
Genset Rated Voltage (V) & Current (A) |
Genset Net Weight (KG) |
| CCFJ40 | SC4H95CF2 | 60 | 10.1 | 40/50 & 44/55 | 50 | 400 & 74 | 790 |
| CCFJ50 | SC4H95CF2 | 60 | 12.6 | 50/62 & 55/69 | 50 | 400 & 90 | 830 |
| CCFJ65 | SC4H115CF2 | 76 | 16.4 | 65/81 & 72/90 | 50 | 400 & 117 | 910 |
| CCFJ80 | SC4H160CF2 | 102 | 20.1 | 80/110 & 88/110 | 50 | 400 & 141 | 960 |
| CCFJ100 | SC4H180CF2 | 117 | 25.2 | 100/125 & 110/138 | 50 | 400 & 173 | 1050 |
| CCFJ120 | SC7H230CF2 | 149 | 29.9 | 120/150 & 132/165 | 50 | 400 & 217 | 1220 |
| CCFJ140 | SC7H250CF2 | 163 | 34.9 | 140/175 & 154/192 | 50 | 400 & 253 | 1350 |
| Prod Model: | CCFJ50 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fuel Oil: | MGO Only |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Basic Diesel Generator |
| Output Type: | AC Three Phase |
| Landuse Type Of Unit: | Marine |
