1. Max. AC output: 850W
2. Rated AC output: 750W
3. Advanced brushless alternator design
4. Convenient control panel with overload circuit breaker protection.
|
Gen Head |
Type |
|
brushless, 2 pole, single-phase |
|
Frequency |
Hz |
60Hz |
|
Voltage |
V |
110-120 |
|
Max. AC output |
KVA |
0.85 |
|
Rated AC output |
KVA |
0.75 |
|
Voltage regulator |
|
condenser |
|
THD |
% |
|
|
Power Factor |
cosΦ |
1 |
|
Structure |
Frame |
|
Portable |
|
Handle |
|
without |
|
Wheel |
|
2*3" Rubber round |
|
Fuel tank capacity |
L |
4.2 |
|
Cont. working time at 50% load |
H |
5.9~6.3 |
|
Engine |
Model |
|
1E45F |
|
Type |
|
Forced air-cooled, 2-stroke, single cylinder, |
|
Displacement |
cc |
63 |
|
Recommended Fuel |
|
gasoline and oil mixing ratio 40: 1 |
|
Max. output |
HP |
2 |
|
Oil capacity |
L |
|
|
Start mode |
|
recoil |
|
Noise level(7m) |
dB(A) |
60~61 |
|
Feature |
Low oil protect |
|
without |
|
Fuel gauge |
|
without |
|
AC voltage |
|
without |
|
Hour meter |
|
without |
|
Indicator Light |
|
with |
|
AC circuit breaker |
|
with |
|
Battery charge |
|
without |
|
Receptacle |
|
|
|
Battery tray kit |
|
without |
|
Package |
Package Dimension |
mm |
430*340*380 |
|
Gross Weight |
kg |
23 |
|
40’ /Per 40' GP container |
unit |
660 |
|
20’ /Per 20' GP container |
unit |
300 |
Shanghai Robot Power Machinery Co., Ltd is Located at Shanghai Fengjing Industrial Area, the Yangtze River Delta, Shanghai Robot Machinery Co., Ltd. was founded in 2003, covers an area of 60 mu. (The first phase of 22, 000 m2 and the second phase of 16, 000 m2 construction area has been completed). Robot now has more than 180 employees including 48 junior and senior engineers and techinicians, the most advanced R&D center developing gasoline engines (horizontal shaft and vertical shaft) and garden machinery using these engines.
Shanghai Robot is a high-tech enterprise with the right to do import and export business. Robot now has 10 auto-assembly lines, advanced research and development center, testing center and laboratory. At present, Robot has an annual production capacity of 1, 200, 000 units general-purpose gasoline engines and 400, 000 sets garden machinery including mower, cultivator, snow sweeper.
By integrating scientific research, manufacturing, marketing, logistics together, Robot has built a platform to synchronize itself with the international market and started doing business in accordance with the eperating mode of big international companies.
Robot Company has passed ISO9002 quality system certifications, and its products also have passed such certifications as EPA, CSA, CARB, CE, EUII, EMC, AND GS, Robot Company has its own brand named "ROBOT" and three patents for its engines with vertical shaft.
