Hummer 2000W 48V Wind Generator
1. Product Features:
1) SCF Supercritical generator
Hummer's 2000W wind generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator's weight and size down to 25% to 30% of the traditional one, and the production efficiency is 25% to 30% higher. This ensures that the generator functions perfectly in small wind condition.
2) SKF bearings
Hummer 2000W wind generator adopts two SKF (Svenska Kullager Fabriken) bearings which are produced by the largest bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. Ordinary bearings need to be changed every two or three years, while SKF bearings can greatly reduce the maintenance costs on this matter.
3) Low noise
The design of the rotor blade of Hummer 2000W wind generator absorbs the highlights of the small aircraft's airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.
4) Double braking protection
Hummer 2000W wind generator adopts the double braking protection system, which are the yawing mechanism and the electromagnetic braking system to regulate the rotation of the wind turbine. It is safe and convenient to shut down the whole system both manually and automatically.
2. Application of 2000W wind generator:
1) Housing, office, farm and factory;
2) Telecommunications Station;
3) TV Transfer Station;
4) Monitoring Station (military, hydrology, observatory)
5) Water-pumping Station;
3. Currently Product Range:
1) 500W-200kW wind turbine Off-grid /Grid-tied;
2) 400W-600W Wind-Solar LED street light and traffic light;
3) Wind-Solar hybrid generating system;
4) Wind-Solar-Diesel hybrid generating system.
|
Rated power(W) |
2000 |
|
Maximum output power(W) |
3200 |
|
Charging voltage(V) |
DC48V |
|
Blade quantity(PCS) |
3 |
|
Rotor blade material |
GRP |
|
Rotor blade diameter(m) |
3.8 |
|
Start-up wind speed(m/s) |
3.0 |
|
Rated wind speed(m/s) |
9.0 |
|
Rated rotating rate(r/min) |
450 |
|
Wind energy utilizing ratio(Cp) |
0.45 |
|
Generator output |
Single-phase frequency conversion AC |
|
Rated charging current(A) |
16.7 |
|
The maximum charging current(in a short time)(A) |
28 |
|
Output AC frequency(Hz) |
0-370 |
|
Generator efficiency |
> 0.8 |
|
Tower height(m) |
10m |
|
Generator weight(kg) |
25 |
