Feature:
1. With large capacity fuel tank, with fuel guage.
2. Gensets with low oil pressure. Over-voltage, over-loaded protection system, running safely and reliable.
3. Several control panel models: ATS, intelligent digital, normal panel or remote control panel, ect, for clients option.
4. Portable beautiful shape, wiht wheel and handle.
5. Anti-shock design.
6. Single phase or three phase alternator for clients option.
7. The output power can be enlarged by fixed with engine BN186FA according to clients request.
8. ISO2000-9001, CE, GS approval.
9. The dimension is the outer sizes of the packages.
|
Model |
BN5800-HB |
BN5800DSE/D |
BN5800DSE-3 |
BN5800-3(B ) |
|
Engine model |
BN186F/E |
BN186FA/E |
|
Rated output power (Kw) |
4.2 |
4.5 |
4.2 |
4.5 |
4.2/1.4 |
4.5/1.5 |
4.2/3.0 |
|
Max output power (Kw) |
4.5 |
5.0 |
4.5 |
5.0 |
4.5 |
5.0 |
5.0/3.3 |
|
Rated frequency (Hz) |
50 |
60 |
50 |
60 |
50 |
60 |
50 |
|
Rated voltage (V) |
230 |
240/120 |
230 |
240/120 |
400/230 |
420/240 |
400/230 |
|
Rated current (A) |
18.3 |
18.8/37.5 |
18.3 |
18.8/37.5 |
6.1/6.1 |
6.2/6.3 |
6.1/13 |
|
Rated rotation speed (rpm) |
3000/3600 |
3000 |
|
Bore×Stroke (mm) |
86×70 |
86×72 |
|
Compression ratio |
19:01 |
|
Lubrication system |
Pressure splashed |
|
Fuel consumption (g/kw.h) |
273/286 |
286 |
|
Rotation direction |
Clockwise |
|
Fuel type |
(summer)0#; (winter)10# |
|
Lube oil type |
SAE-10W30 (above DC grade) |
|
Power factor (cos φ) |
1.0 |
|
Phase number |
Single phase |
three phase |
|
Structure type |
Silent type |
|
Starting system |
Recoil stater/Electric starter |
|
Fuel tank capacity (L) |
16 |
|
Lube capacity (L) |
1.65 |
|
Noise level (dBA) |
75 |
|
Overall dimension (mm) |
wooden chassis pakage:960 x 560 x 830 / (carton pakage:960 x 560 x 760) |
|
|
|
|
|
960×560×830 |
|
Net weight (kg) |
165 |
