Input volt. DC 10.5-15V
Static current (on)DC12V, ≤ 1.5A
Static current (off)DC12V, ≤ 0.2A
Output volt. AC220V± 5%
Frequency 50Hz± 1%
Wave type quosi-sine wave
Efficiency DC12V, >80%
Rated power DC12V, < 600W
Continuous power DC12V, < 600W
Peak power: 1000W
Allowed over-load 650W---800W, within 10 seconds
Surge over-load>1000W within 1 second
Low power alarmdc 10.5V
Low power protectiondc 9.9V
Fan working fan start working when load>150W, fan at high speed working when load >400W, fan at high speed working when charging current>3A, fan at low speed working 1A&< Current< 2.5A.
Over-load alarm load>650W
Over-load protection last about 10 seconds and shut down, to recovery it need unload in hand
Surge short circuit protection shut down in one second, and need solve the short circuit and recovery it in hand
Reverse connection protection fuse burned
Charging type three-step charging(constant-voltage, constant-current and trickle charge)
Input of charger AC(180-260V)
Max charging current: 10A
Max charging voltage: 14.2V
AC output transfer 10ms
Alenson Electronics is one of the fastest growing, innovative manufacturers specialising in the development and production of digital & AV products.
Our products include: Power Inverter, APC UPS, PC Power; Portable & Standalone DVD/DIVX player; Home theatre; MP3 player with camera; Etc. With a team of more than 60 talented engineers, we could fulfill the whole process such as idea creation for new products, industrial design, software programming, mas production and so on.
Our production base has several SMT machines, fully-automatic production lines and other advanced facilities, we now have a combined daily output volume capacity exceeding 10, 000 sets.
