10kVA/8KW power Diesel Generator Set
Generator Supply Scope:
1. Engine, alternator, radiator, auto control panel.
2. Base frame, base fuel tank, Flexible pipes, flange, exhaust silencer.
3. Battery, battery charger, battery wires, internal cables, circuit breaker.
4. Manual books of engine, alternator, genset, control panel, wires diagram
Other Optional part:
Silent canopy, movable trailer, ATS, synchronization system, etc.
|
Diesel Power Generator Set Data Manufacturer |
Perkins Engines Company Limited |
|
Model |
403D-11G |
|
Engine speed |
1500rpm |
|
Engine power |
|
|
--------------------Prime power (Gross) |
8.6 kWm / 11.5 bhp |
|
(Net) |
8.4 kWm / 11.4 bhp |
|
--------------------Standby power (Gross) |
9.5 kWm / 12.7 bhp |
|
(Net) |
9.3 kWm / 12.6 bhp |
|
General Data Number of cylinders |
3 |
|
Cylinder arrangement |
Vertical in-line |
|
Cycle |
4 stroke |
|
Aspiration |
Naturally aspirated |
|
Combustion system |
Indirect injection |
|
Compression ratio |
23: 1 |
|
Bore and Stroke |
77 * 81 mm |
|
Displacment |
1.131 litres |
|
Direction of rotation |
Anti-clockwise viewed on flywheel |
|
Cooling system |
Water cooled |
|
Total coolant capacity |
5.2 litres |
|
Total lubrication system capacity |
4.9 litres |
|
Fuel Consumption Engine Speed |
Fuel consumption |
|
|
g/kw. h |
L/h |
|
Standby power |
261 |
2.9 |
|
Prime power |
252 |
2.6 |
|
75% of prime power |
258 |
2.0 |
|
50% of prime power |
286 |
1.5 |
|
ALTERNATOR GENERAL DATA Manufacturer |
Leroy-somer Electro-technique (Fuzhou) Company Ltd. |
|
Model |
LSA42.2 VS0 |
|
Output power |
8KW |
|
AVR model |
R250 |
|
Number of phase |
3 |
|
Power factor (Cos Phi) |
0.8 |
|
Altitude |
≤ 1000 m |
|
Overspeed |
2250RPM |
|
Number of Pole |
4 |
|
Exciter type |
Shunt |
|
Insulation class |
H |
|
Voltage regulation |
± 0.5% |
|
Sustained short circuit current |
300% (3 IN) : 10s |
|
Total harmonics (TGH/THC) |
< 4 % |
|
Wave form : NEMA = TIF |
< 50 |
|
Wave form : I. E. C. = THF |
< 2% |
|
Bearing |
single |
|
Coupling |
Direct
|
