Engine type 4stock, overhead valve, single cylinder
Displacement 37.5CC
Bore*stroke Φ 40.0*30mm
Compression ratio 10: 1
Engine speed 4200~5, 500r. P. M
Oil capacity 0.15L
Fuel tank capacity 1.6L
Spark plug A7RTC
Noise Level(ISO 8528-10) 58dB(A)
Generator
Rated voltage(V) 220/230/240 110/120
Rated Frequendy(Hz) 50 60
Rated output(VA) 750 750
Max output(VA) 850 1600(IN1500I)
Dimensions and Weight
Length*Width*Height 445*235*370mm
Dry weight 12.5kg
MODEL N. W/G. W(KGS) DIMENSION (MM) SET/CTN (PCS) 20'FT
IN800I 12.5/14 460*255*395 1 560
Suzhou Defeng Electrical Machine Co., Ltd is a high-tech enterprise with Various Generators, water pump production, R & D and sales department manufatuer. All products is entiled with Kaijieli Brand include Medium and small sizes of AC Generators or alternators with brush and brushless, and pumps. More than 10 patents have been approved and recognized as the fames of "Products exemption from quality surveillance inspection" "Provincial famous products", "Provincial quality reliable products", "Excellent and famous new products in Machinery industry of China". Meanwhile, we have got the certificates of "CCC""CE""TUV" and "GS".
Our annual production output has reached over 10, 000, 000 (five million) KW. Kaijieli Brand Products have good markets at home and abroad, 75% of the products exported to more than 80 different countries, including Europe, American countries, Middle East, Australia, Africa, South-east Asia and so on.
Defeng company receives more and more reputation in domestic and overseas. Kaijieli brand products has become the pioneer in its field. It has been recognized as "Provincial famous brand" and registered in many continents and countries. Furthemore, It has been approved as "Most influential brand in Machinery industry of China", Kaijieli Brand has become a TOP famous brand in electric machinery industry filed in China.
